Connor-Winfield发布符合Stratum3E标准的14脚OCXO6G设备晶振,OH4610LF-024.576M晶振

来源：亿金电子查看手机网址

扫一扫!

Connor-Winfield发布符合Stratum3E标准的14脚OCXO6G设备晶振,OH4610LF-024.576M晶振

扫一扫!

浏览：- 发布日期：2023-06-21 13:58:36【大中小】

分享到：

Connor-Winfield发布符合Stratum3E标准的14脚OCXO6G设备,OH4610LF-024.576M晶振，伊利诺伊州奥罗拉，ConnorWinfield晶振公司新推出的OH414针DIP系列OCXO是基于SC切割晶体的振荡器专门设计用于与<1mH至.1Hz的低滤波器带宽配合使用，以符合基于T1的层次结构规范，例如ITU-TG.8262选项1和2ECC、ITU-TG.8263、ITU-TG.813选项1和2SEC，用于Sonet、IEEE1588和同步以太网的第3层和3E层。CW的OH4OCXO系列采用小尺寸14x20mm作为SMD或14引脚DIP通孔封装。

OH4OCXO晶振系列配置选项提供10ppb峰峰值频率稳定性、-40至+85C的工业温度范围以及出色的性能，低相位噪声、短期稳定性和老化特性。

Connor-Winfield发布符合Stratum3E标准的14脚OCXO6G设备,OH4610LF-024.576M晶振

特征：

•可用频率范围从10MHz到100MHz，标准频率为12.8MHz，19.2MHz、19.44MHz、20MHz、24.576MHz、25MHz、38.88MHz、40MHz和100MHz。

•3.3VLVCMOS或正弦输出

•固定输出或电压控制

•符合在.1Hz带宽下测量的层级MTIE和TDEV掩模

•10ppb峰峰值温度稳定性

•在12kHz-20MHz频段内低于300ps的抖动性能

•使用寿命精度为+/-1ppm

•完全符合ROHS和REACH标准

•14x20mm贴片或通孔封装选项

原厂代码	品牌	型号	类型	频率	输出	电压	频率稳定度	工作温度
DGOF5S3-020.0M	Connor-Winfield	DGOF	OCXO	20MHz	HCMOS, TTL	5V	250ppb	0°C ~ 70°C
DGOF5S3-010.0M	Connor-Winfield	DGOF	OCXO	10MHz	HCMOS, TTL	5V	250ppb	0°C ~ 70°C
DOCSC022F-025.0M	Connor-Winfield	DOCSC	OCXO	25MHz	LVCMOS	3.3V	±20ppb	-40°C ~ 85°C
DOCSC022F-025.0M	Connor-Winfield	DOCSC	OCXO	25MHz	LVCMOS	3.3V	±20ppb	-40°C ~ 85°C
DOCSC022F-025.0M	Connor-Winfield	DOCSC	OCXO	25MHz	LVCMOS	3.3V	±20ppb	-40°C ~ 85°C
OH4610LF-040.0M	Connor-Winfield	OH4	OCXO	40MHz	LVCMOS	3.3V	±10ppb	-40°C ~ 85°C
OH4610LF-025.0M	Connor-Winfield	OH4	OCXO	25MHz	LVCMOS	3.3V	±10ppb	-40°C ~ 85°C
OH100-61003CF-010.0M	Connor-Winfield	OH100	OCXO	10MHz	CMOS	3.3V	±10ppb	-40°C ~ 85°C
OH300-61003CF-010.0M	Connor-Winfield	OH300	OCXO	10MHz	CMOS	3.3V	±10ppb	-40°C ~ 85°C
OH300-61003CF-010.0M	Connor-Winfield	OH300	OCXO	10MHz	CMOS	3.3V	±10ppb	-40°C ~ 85°C
OH300-61003CF-010.0M	Connor-Winfield	OH300	OCXO	10MHz	CMOS	3.3V	±10ppb	-40°C ~ 85°C
BSOF3S3E-010.0M	Connor-Winfield	BSOF3S3E	OCXO	10MHz	HCMOS	3.3V	±10ppb	0°C ~ 70°C
ASOF3S3-020.0M	Connor-Winfield	ASOF3S3	OCXO	20MHz	LVCMOS	3.3V	250ppb	0°C ~ 70°C
ASOF3S3-012.8M	Connor-Winfield	ASOF3S3	OCXO	12.8MHz	LVCMOS	3.3V	250ppb	0°C ~ 70°C
OH100-50503CF-010.0M	Connor-Winfield	OH100	OCXO	10MHz	CMOS	3.3V	±5ppb	0°C ~ 70°C
OH100-50503CF-012.8M	Connor-Winfield	OH100	OCXO	12.8MHz	CMOS	3.3V	±5ppb	0°C ~ 70°C
OH100-61003CF-020.0M	Connor-Winfield	OH100	OCXO	20MHz	CMOS	3.3V	±10ppb	-40°C ~ 85°C
ASOF3S3-010.0M	Connor-Winfield	ASOF3S3	OCXO	10MHz	LVCMOS	3.3V	250ppb	0°C ~ 70°C
OH100-61003CF-012.8M	Connor-Winfield	OH100	OCXO	12.8MHz	CMOS	3.3V	±10ppb	-40°C ~ 85°C
OX400-620LF-020.0M	Connor-Winfield	OX400-620LF	OCXO	20MHz	LVCMOS	3.3V	±20ppb	-40°C ~ 85°C
OX400-620LF-024.576M	Connor-Winfield	OX400-620LF	OCXO	24.576MHz	LVCMOS	3.3V	±20ppb	-40°C ~ 85°C
OH4610LF-38.88M	Connor-Winfield	OH4	OCXO	38.88MHz	LVCMOS	3.3V	±10ppb	-40°C ~ 85°C
OH100-70503CF-024.576M	Connor-Winfield	OH100	OCXO	24.576MHz	CMOS	3.3V	±5ppb	-20°C ~ 70°C
OH100-70503CF-020.0M	Connor-Winfield	OH100	OCXO	20MHz	CMOS	3.3V	±5ppb	-20°C ~ 70°C
OH300-70503CF-020.0M	Connor-Winfield	OH300	OCXO	20MHz	CMOS	3.3V	±5ppb	-20°C ~ 70°C
OH300-70503CF-020.0M	Connor-Winfield	OH300	OCXO	20MHz	CMOS	3.3V	±5ppb	-20°C ~ 70°C
OH300-70503CF-020.0M	Connor-Winfield	OH300	OCXO	20MHz	CMOS	3.3V	±5ppb	-20°C ~ 70°C
OHSM100-60803CF-010.0M	Connor-Winfield	OHSM100-60803CF	OCXO	10MHz	LVCMOS	3.3V	±8ppm	-40°C ~ 85°C
OH200-61003CF-024.576M	Connor-Winfield	OH200	OCXO	24.576MHz	CMOS	3.3V	±5ppb	-40°C ~ 85°C
OH100-60503CF-024.576M	Connor-Winfield	OH100	OCXO	24.576MHz	CMOS	3.3V	±5ppb	-40°C ~ 85°C
OH200-61003CF-020.0M	Connor-Winfield	OH200	OCXO	20MHz	CMOS	3.3V	±5ppb	-40°C ~ 85°C
DOCSC022F-024.576M	Connor-Winfield	DOCSC	OCXO	24.576MHz	LVCMOS	3.3V	±20ppb	-40°C ~ 85°C
DOCSC022F-024.576M	Connor-Winfield	DOCSC	OCXO	24.576MHz	LVCMOS	3.3V	±20ppb	-40°C ~ 85°C
DOCSC022F-024.576M	Connor-Winfield	DOCSC	OCXO	24.576MHz	LVCMOS	3.3V	±20ppb	-40°C ~ 85°C
OH200-51003CF-012.8M	Connor-Winfield	OH200	OCXO	12.8MHz	CMOS	3.3V	±5ppb	0°C ~ 70°C
OH200-51003CF-005.0M	Connor-Winfield	OH200	OCXO	5MHz	CMOS	3.3V	±5ppb	0°C ~ 70°C
OH100-50503CF-020.0M	Connor-Winfield	OH100	OCXO	20MHz	CMOS	3.3V	±5ppb	0°C ~ 70°C
OH300-61003CF-012.8M	Connor-Winfield	OH300	OCXO	12.8MHz	CMOS	3.3V	±10ppb	-40°C ~ 85°C
OH300-61003CF-012.8M	Connor-Winfield	OH300	OCXO	12.8MHz	CMOS	3.3V	±10ppb	-40°C ~ 85°C
OH300-61003CF-012.8M	Connor-Winfield	OH300	OCXO	12.8MHz	CMOS	3.3V	±10ppb	-40°C ~ 85°C
OH300-50503CF-020.0M	Connor-Winfield	OH300	OCXO	20MHz	CMOS	3.3V	±5ppb	0°C ~ 70°C
OH300-50503CF-020.0M	Connor-Winfield	OH300	OCXO	20MHz	CMOS	3.3V	±5ppb	0°C ~ 70°C
OH300-50503CF-020.0M	Connor-Winfield	OH300	OCXO	20MHz	CMOS	3.3V	±5ppb	0°C ~ 70°C
OH300-70503CF-024.576M	Connor-Winfield	OH300	OCXO	24.576MHz	CMOS	3.3V	±5ppb	-20°C ~ 70°C
OH300-70503CF-024.576M	Connor-Winfield	OH300	OCXO	24.576MHz	CMOS	3.3V	±5ppb	-20°C ~ 70°C
OH300-70503CF-024.576M	Connor-Winfield	OH300	OCXO	24.576MHz	CMOS	3.3V	±5ppb	-20°C ~ 70°C
OH300-50503CF-012.8M	Connor-Winfield	OH300	OCXO	12.8MHz	CMOS	3.3V	±5ppb	0°C ~ 70°C
OH300-50503CF-012.8M	Connor-Winfield	OH300	OCXO	12.8MHz	CMOS	3.3V	±5ppb	0°C ~ 70°C
OH300-50503CF-012.8M	Connor-Winfield	OH300	OCXO	12.8MHz	CMOS	3.3V	±5ppb	0°C ~ 70°C
OH300-60503CF-024.576M	Connor-Winfield	OH300	OCXO	24.576MHz	CMOS	3.3V	±5ppb	-40°C ~ 85°C
OH300-60503CF-024.576M	Connor-Winfield	OH300	OCXO	24.576MHz	CMOS	3.3V	±5ppb	-40°C ~ 85°C
OH300-60503CF-024.576M	Connor-Winfield	OH300	OCXO	24.576MHz	CMOS	3.3V	±5ppb	-40°C ~ 85°C
OH300-61003CF-020.0M	Connor-Winfield	OH300	OCXO	20MHz	CMOS	3.3V	±10ppb	-40°C ~ 85°C
OH300-61003CF-020.0M	Connor-Winfield	OH300	OCXO	20MHz	CMOS	3.3V	±10ppb	-40°C ~ 85°C
OH300-61003CF-020.0M	Connor-Winfield	OH300	OCXO	20MHz	CMOS	3.3V	±10ppb	-40°C ~ 85°C
OH300-50503CF-010.0M	Connor-Winfield	OH300	OCXO	10MHz	CMOS	3.3V	±5ppb	0°C ~ 70°C
OH300-50503CF-010.0M	Connor-Winfield	OH300	OCXO	10MHz	CMOS	3.3V	±5ppb	0°C ~ 70°C
OH300-50503CF-010.0M	Connor-Winfield	OH300	OCXO	10MHz	CMOS	3.3V	±5ppb	0°C ~ 70°C
OH300-61003CF-040.0M	Connor-Winfield	OH300	OCXO	40MHz	CMOS	3.3V	±10ppb	-20°C ~ 70°C
OH300-61003CF-040.0M	Connor-Winfield	OH300	OCXO	40MHz	CMOS	3.3V	±10ppb	-20°C ~ 70°C
OH300-61003CF-040.0M	Connor-Winfield	OH300	OCXO	40MHz	CMOS	3.3V	±10ppb	-20°C ~ 70°C
OHSM100-60803CF-020.0M	Connor-Winfield	OHSM100-60803CF	OCXO	20MHz	LVCMOS	3.3V	±8ppm	-40°C ~ 85°C
DOCSC022F-040.0M	Connor-Winfield	DOCSC	OCXO	40MHz	LVCMOS	3.3V	±20ppb	-40°C ~ 85°C
DOCSC022F-040.0M	Connor-Winfield	DOCSC	OCXO	40MHz	LVCMOS	3.3V	±20ppb	-40°C ~ 85°C
DOCSC022F-040.0M	Connor-Winfield	DOCSC	OCXO	40MHz	LVCMOS	3.3V	±20ppb	-40°C ~ 85°C
OH4610LF-024.576M	Connor-Winfield	OH4	OCXO	24.576MHz	LVCMOS	3.3V	±10ppb	-40°C ~ 85°C
DOCSC022F-020.0M	Connor-Winfield	DOCSC	OCXO	20MHz	LVCMOS	3.3V	±20ppb	-40°C ~ 85°C
DOCSC022F-020.0M	Connor-Winfield	DOCSC	OCXO	20MHz	LVCMOS	3.3V	±20ppb	-40°C ~ 85°C
DOCSC022F-020.0M	Connor-Winfield	DOCSC	OCXO	20MHz	LVCMOS	3.3V	±20ppb	-40°C ~ 85°C
OH4610LF-012.8M	Connor-Winfield	OH4	OCXO	12.8MHz	LVCMOS	3.3V	±10ppb	-40°C ~ 85°C
OH4610LF-010.0M	Connor-Winfield	OH4	OCXO	10MHz	LVCMOS	3.3V	±10ppb	-40°C ~ 85°C
OH4610LF-020.0M	Connor-Winfield	OH4	OCXO	20MHz	LVCMOS	3.3V	±10ppb	-40°C ~ 85°C
ASOF5S3-012.8M	Connor-Winfield	ASOF5S3	OCXO	12.8MHz	HCMOS	5V	250ppb	0°C ~ 70°C
ASOF5S3-019.44M	Connor-Winfield	ASOF5S3	OCXO	19.44MHz	HCMOS	5V	250ppb	0°C ~ 70°C
OH200-51003CF-010.0M	Connor-Winfield	OH200	OCXO	10MHz	CMOS	3.3V	±5ppb	0°C ~ 70°C
OFC5DJ3BS-010.0M	Connor-Winfield	OFC5DJ3BS	OCXO	10MHz	Sine Wave	5V	±20ppb	-20°C ~ 70°C
OFC5DJ3BS-020.0M	Connor-Winfield	OFC5DJ3BS	OCXO	20MHz	Sine Wave	5V	±20ppb	-20°C ~ 70°C
DOCSC012F-020.0M	Connor-Winfield	DOCSC	OCXO	20MHz	LVCMOS	3.3V	±10ppb	-40°C ~ 85°C
OH300-50503CF-025.0M	Connor-Winfield	OH300	OCXO	25MHz	CMOS	3.3V	±5ppb	0°C ~ 70°C
OH300-50503CF-025.0M	Connor-Winfield	OH300	OCXO	25MHz	CMOS	3.3V	±5ppb	0°C ~ 70°C
OH300-50503CF-025.0M	Connor-Winfield	OH300	OCXO	25MHz	CMOS	3.3V	±5ppb	0°C ~ 70°C
OH300-50503CF-040.0M	Connor-Winfield	OH300	OCXO	40MHz	CMOS	3.3V	±5ppb	0°C ~ 70°C
OH300-50503CF-040.0M	Connor-Winfield	OH300	OCXO	40MHz	CMOS	3.3V	±5ppb	0°C ~ 70°C
OH300-50503CF-040.0M	Connor-Winfield	OH300	OCXO	40MHz	CMOS	3.3V	±5ppb	0°C ~ 70°C
OH300-61003CF-025.0M	Connor-Winfield	OH300	OCXO	25MHz	CMOS	3.3V	±10ppb	-40°C ~ 85°C
OH300-61003CF-025.0M	Connor-Winfield	OH300	OCXO	25MHz	CMOS	3.3V	±10ppb	-40°C ~ 85°C
OH300-61003CF-025.0M	Connor-Winfield	OH300	OCXO	25MHz	CMOS	3.3V	±10ppb	-40°C ~ 85°C
DOCSC012F-040.0M	Connor-Winfield	DOCSC	OCXO	40MHz	LVCMOS	3.3V	±10ppb	-40°C ~ 85°C
OH300-50503CF-050.0M	Connor-Winfield	OH300	OCXO	50MHz	CMOS	3.3V	±5ppb	0°C ~ 70°C
OH300-50503CF-050.0M	Connor-Winfield	OH300	OCXO	50MHz	CMOS	3.3V	±5ppb	0°C ~ 70°C
OH300-50503CF-050.0M	Connor-Winfield	OH300	OCXO	50MHz	CMOS	3.3V	±5ppb	0°C ~ 70°C
OH300-61003CF-050.0M	Connor-Winfield	OH300	OCXO	50MHz	CMOS	3.3V	±10ppb	-40°C ~ 85°C
OH300-61003CF-050.0M	Connor-Winfield	OH300	OCXO	50MHz	CMOS	3.3V	±10ppb	-40°C ~ 85°C
OH300-61003CF-050.0M	Connor-Winfield	OH300	OCXO	50MHz	CMOS	3.3V	±10ppb	-40°C ~ 85°C
