Connor-Winfield发布符合Stratum3E标准的14脚OCXO6G设备晶振,OH4610LF-024.576M晶振

2023-06-21 13:58:36

康纳 温菲尔德新闻2.1

Connor-Winfield发布符合Stratum3E标准的14脚OCXO6G设备,OH4610LF-024.576M晶振伊利诺伊州奥罗拉,ConnorWinfield晶振公司新推出的OH414针DIP系列OCXO是基于SC切割晶体的振荡器专门设计用于与<1mH至.1Hz的低滤波器带宽配合使用,以符合基于T1的层次结构规范,例如ITU-TG.8262选项1和2ECC、ITU-TG.8263、ITU-TG.813选项1和2SEC,用于Sonet、IEEE1588和同步以太网的第3层和3E层。CW的OH4OCXO系列采用小尺寸14x20mm作为SMD或14引脚DIP通孔封装。

OH4OCXO晶振系列配置选项提供10ppb峰峰值频率稳定性、-40至+85C的工业温度范围以及出色的性能,低相位噪声、短期稳定性和老化特性。

康纳 温菲尔德新闻2.2

Connor-Winfield发布符合Stratum3E标准的14脚OCXO6G设备,OH4610LF-024.576M晶振

特征:

•可用频率范围从10MHz到100MHz,标准频率为12.8MHz,19.2MHz、19.44MHz、20MHz、24.576MHz、25MHz、38.88MHz、40MHz和100MHz。

•3.3VLVCMOS或正弦输出

•固定输出或电压控制

•符合在.1Hz带宽下测量的层级MTIE和TDEV掩模

•10ppb峰峰值温度稳定性

•在12kHz-20MHz频段内低于300ps的抖动性能

•使用寿命精度为+/-1ppm

•完全符合ROHS和REACH标准

•14x20mm贴片或通孔封装选项

原厂代码 品牌 型号 类型 频率 输出 电压 频率稳定度 工作温度
DGOF5S3-020.0M Connor-Winfield DGOF OCXO 20MHz HCMOS, TTL 5V 250ppb 0°C ~ 70°C
DGOF5S3-010.0M Connor-Winfield DGOF OCXO 10MHz HCMOS, TTL 5V 250ppb 0°C ~ 70°C
DOCSC022F-025.0M Connor-Winfield DOCSC OCXO 25MHz LVCMOS 3.3V ±20ppb -40°C ~ 85°C
DOCSC022F-025.0M Connor-Winfield DOCSC OCXO 25MHz LVCMOS 3.3V ±20ppb -40°C ~ 85°C
DOCSC022F-025.0M Connor-Winfield DOCSC OCXO 25MHz LVCMOS 3.3V ±20ppb -40°C ~ 85°C
OH4610LF-040.0M Connor-Winfield OH4 OCXO 40MHz LVCMOS 3.3V ±10ppb -40°C ~ 85°C
OH4610LF-025.0M Connor-Winfield OH4 OCXO 25MHz LVCMOS 3.3V ±10ppb -40°C ~ 85°C
OH100-61003CF-010.0M Connor-Winfield OH100 OCXO 10MHz CMOS 3.3V ±10ppb -40°C ~ 85°C
OH300-61003CF-010.0M Connor-Winfield OH300 OCXO 10MHz CMOS 3.3V ±10ppb -40°C ~ 85°C
OH300-61003CF-010.0M Connor-Winfield OH300 OCXO 10MHz CMOS 3.3V ±10ppb -40°C ~ 85°C
OH300-61003CF-010.0M Connor-Winfield OH300 OCXO 10MHz CMOS 3.3V ±10ppb -40°C ~ 85°C
BSOF3S3E-010.0M Connor-Winfield BSOF3S3E OCXO 10MHz HCMOS 3.3V ±10ppb 0°C ~ 70°C
ASOF3S3-020.0M Connor-Winfield ASOF3S3 OCXO 20MHz LVCMOS 3.3V 250ppb 0°C ~ 70°C
ASOF3S3-012.8M Connor-Winfield ASOF3S3 OCXO 12.8MHz LVCMOS 3.3V 250ppb 0°C ~ 70°C
OH100-50503CF-010.0M Connor-Winfield OH100 OCXO 10MHz CMOS 3.3V ±5ppb 0°C ~ 70°C
OH100-50503CF-012.8M Connor-Winfield OH100 OCXO 12.8MHz CMOS 3.3V ±5ppb 0°C ~ 70°C
OH100-61003CF-020.0M Connor-Winfield OH100 OCXO 20MHz CMOS 3.3V ±10ppb -40°C ~ 85°C
ASOF3S3-010.0M Connor-Winfield ASOF3S3 OCXO 10MHz LVCMOS 3.3V 250ppb 0°C ~ 70°C
OH100-61003CF-012.8M Connor-Winfield OH100 OCXO 12.8MHz CMOS 3.3V ±10ppb -40°C ~ 85°C
OX400-620LF-020.0M Connor-Winfield OX400-620LF OCXO 20MHz LVCMOS 3.3V ±20ppb -40°C ~ 85°C
OX400-620LF-024.576M Connor-Winfield OX400-620LF OCXO 24.576MHz LVCMOS 3.3V ±20ppb -40°C ~ 85°C
OH4610LF-38.88M Connor-Winfield OH4 OCXO 38.88MHz LVCMOS 3.3V ±10ppb -40°C ~ 85°C
OH100-70503CF-024.576M Connor-Winfield OH100 OCXO 24.576MHz CMOS 3.3V ±5ppb -20°C ~ 70°C
OH100-70503CF-020.0M Connor-Winfield OH100 OCXO 20MHz CMOS 3.3V ±5ppb -20°C ~ 70°C
OH300-70503CF-020.0M Connor-Winfield OH300 OCXO 20MHz CMOS 3.3V ±5ppb -20°C ~ 70°C
OH300-70503CF-020.0M Connor-Winfield OH300 OCXO 20MHz CMOS 3.3V ±5ppb -20°C ~ 70°C
OH300-70503CF-020.0M Connor-Winfield OH300 OCXO 20MHz CMOS 3.3V ±5ppb -20°C ~ 70°C
OHSM100-60803CF-010.0M Connor-Winfield OHSM100-60803CF OCXO 10MHz LVCMOS 3.3V ±8ppm -40°C ~ 85°C
OH200-61003CF-024.576M Connor-Winfield OH200 OCXO 24.576MHz CMOS 3.3V ±5ppb -40°C ~ 85°C
OH100-60503CF-024.576M Connor-Winfield OH100 OCXO 24.576MHz CMOS 3.3V ±5ppb -40°C ~ 85°C
OH200-61003CF-020.0M Connor-Winfield OH200 OCXO 20MHz CMOS 3.3V ±5ppb -40°C ~ 85°C
DOCSC022F-024.576M Connor-Winfield DOCSC OCXO 24.576MHz LVCMOS 3.3V ±20ppb -40°C ~ 85°C
DOCSC022F-024.576M Connor-Winfield DOCSC OCXO 24.576MHz LVCMOS 3.3V ±20ppb -40°C ~ 85°C
DOCSC022F-024.576M Connor-Winfield DOCSC OCXO 24.576MHz LVCMOS 3.3V ±20ppb -40°C ~ 85°C
OH200-51003CF-012.8M Connor-Winfield OH200 OCXO 12.8MHz CMOS 3.3V ±5ppb 0°C ~ 70°C
OH200-51003CF-005.0M Connor-Winfield OH200 OCXO 5MHz CMOS 3.3V ±5ppb 0°C ~ 70°C
OH100-50503CF-020.0M Connor-Winfield OH100 OCXO 20MHz CMOS 3.3V ±5ppb 0°C ~ 70°C
OH300-61003CF-012.8M Connor-Winfield OH300 OCXO 12.8MHz CMOS 3.3V ±10ppb -40°C ~ 85°C
OH300-61003CF-012.8M Connor-Winfield OH300 OCXO 12.8MHz CMOS 3.3V ±10ppb -40°C ~ 85°C
OH300-61003CF-012.8M Connor-Winfield OH300 OCXO 12.8MHz CMOS 3.3V ±10ppb -40°C ~ 85°C
OH300-50503CF-020.0M Connor-Winfield OH300 OCXO 20MHz CMOS 3.3V ±5ppb 0°C ~ 70°C
OH300-50503CF-020.0M Connor-Winfield OH300 OCXO 20MHz CMOS 3.3V ±5ppb 0°C ~ 70°C
OH300-50503CF-020.0M Connor-Winfield OH300 OCXO 20MHz CMOS 3.3V ±5ppb 0°C ~ 70°C
OH300-70503CF-024.576M Connor-Winfield OH300 OCXO 24.576MHz CMOS 3.3V ±5ppb -20°C ~ 70°C
OH300-70503CF-024.576M Connor-Winfield OH300 OCXO 24.576MHz CMOS 3.3V ±5ppb -20°C ~ 70°C
OH300-70503CF-024.576M Connor-Winfield OH300 OCXO 24.576MHz CMOS 3.3V ±5ppb -20°C ~ 70°C
OH300-50503CF-012.8M Connor-Winfield OH300 OCXO 12.8MHz CMOS 3.3V ±5ppb 0°C ~ 70°C
OH300-50503CF-012.8M Connor-Winfield OH300 OCXO 12.8MHz CMOS 3.3V ±5ppb 0°C ~ 70°C
OH300-50503CF-012.8M Connor-Winfield OH300 OCXO 12.8MHz CMOS 3.3V ±5ppb 0°C ~ 70°C
OH300-60503CF-024.576M Connor-Winfield OH300 OCXO 24.576MHz CMOS 3.3V ±5ppb -40°C ~ 85°C
OH300-60503CF-024.576M Connor-Winfield OH300 OCXO 24.576MHz CMOS 3.3V ±5ppb -40°C ~ 85°C
OH300-60503CF-024.576M Connor-Winfield OH300 OCXO 24.576MHz CMOS 3.3V ±5ppb -40°C ~ 85°C
OH300-61003CF-020.0M Connor-Winfield OH300 OCXO 20MHz CMOS 3.3V ±10ppb -40°C ~ 85°C
OH300-61003CF-020.0M Connor-Winfield OH300 OCXO 20MHz CMOS 3.3V ±10ppb -40°C ~ 85°C
OH300-61003CF-020.0M Connor-Winfield OH300 OCXO 20MHz CMOS 3.3V ±10ppb -40°C ~ 85°C
OH300-50503CF-010.0M Connor-Winfield OH300 OCXO 10MHz CMOS 3.3V ±5ppb 0°C ~ 70°C
OH300-50503CF-010.0M Connor-Winfield OH300 OCXO 10MHz CMOS 3.3V ±5ppb 0°C ~ 70°C
OH300-50503CF-010.0M Connor-Winfield OH300 OCXO 10MHz CMOS 3.3V ±5ppb 0°C ~ 70°C
OH300-61003CF-040.0M Connor-Winfield OH300 OCXO 40MHz CMOS 3.3V ±10ppb -20°C ~ 70°C
OH300-61003CF-040.0M Connor-Winfield OH300 OCXO 40MHz CMOS 3.3V ±10ppb -20°C ~ 70°C
OH300-61003CF-040.0M Connor-Winfield OH300 OCXO 40MHz CMOS 3.3V ±10ppb -20°C ~ 70°C
OHSM100-60803CF-020.0M Connor-Winfield OHSM100-60803CF OCXO 20MHz LVCMOS 3.3V ±8ppm -40°C ~ 85°C
DOCSC022F-040.0M Connor-Winfield DOCSC OCXO 40MHz LVCMOS 3.3V ±20ppb -40°C ~ 85°C
DOCSC022F-040.0M Connor-Winfield DOCSC OCXO 40MHz LVCMOS 3.3V ±20ppb -40°C ~ 85°C
DOCSC022F-040.0M Connor-Winfield DOCSC OCXO 40MHz LVCMOS 3.3V ±20ppb -40°C ~ 85°C
OH4610LF-024.576M Connor-Winfield OH4 OCXO 24.576MHz LVCMOS 3.3V ±10ppb -40°C ~ 85°C
DOCSC022F-020.0M Connor-Winfield DOCSC OCXO 20MHz LVCMOS 3.3V ±20ppb -40°C ~ 85°C
DOCSC022F-020.0M Connor-Winfield DOCSC OCXO 20MHz LVCMOS 3.3V ±20ppb -40°C ~ 85°C
DOCSC022F-020.0M Connor-Winfield DOCSC OCXO 20MHz LVCMOS 3.3V ±20ppb -40°C ~ 85°C
OH4610LF-012.8M Connor-Winfield OH4 OCXO 12.8MHz LVCMOS 3.3V ±10ppb -40°C ~ 85°C
OH4610LF-010.0M Connor-Winfield OH4 OCXO 10MHz LVCMOS 3.3V ±10ppb -40°C ~ 85°C
OH4610LF-020.0M Connor-Winfield OH4 OCXO 20MHz LVCMOS 3.3V ±10ppb -40°C ~ 85°C
ASOF5S3-012.8M Connor-Winfield ASOF5S3 OCXO 12.8MHz HCMOS 5V 250ppb 0°C ~ 70°C
ASOF5S3-019.44M Connor-Winfield ASOF5S3 OCXO 19.44MHz HCMOS 5V 250ppb 0°C ~ 70°C
OH200-51003CF-010.0M Connor-Winfield OH200 OCXO 10MHz CMOS 3.3V ±5ppb 0°C ~ 70°C
OFC5DJ3BS-010.0M Connor-Winfield OFC5DJ3BS OCXO 10MHz Sine Wave 5V ±20ppb -20°C ~ 70°C
OFC5DJ3BS-020.0M Connor-Winfield OFC5DJ3BS OCXO 20MHz Sine Wave 5V ±20ppb -20°C ~ 70°C
DOCSC012F-020.0M Connor-Winfield DOCSC OCXO 20MHz LVCMOS 3.3V ±10ppb -40°C ~ 85°C
OH300-50503CF-025.0M Connor-Winfield OH300 OCXO 25MHz CMOS 3.3V ±5ppb 0°C ~ 70°C
OH300-50503CF-025.0M Connor-Winfield OH300 OCXO 25MHz CMOS 3.3V ±5ppb 0°C ~ 70°C
OH300-50503CF-025.0M Connor-Winfield OH300 OCXO 25MHz CMOS 3.3V ±5ppb 0°C ~ 70°C
OH300-50503CF-040.0M Connor-Winfield OH300 OCXO 40MHz CMOS 3.3V ±5ppb 0°C ~ 70°C
OH300-50503CF-040.0M Connor-Winfield OH300 OCXO 40MHz CMOS 3.3V ±5ppb 0°C ~ 70°C
OH300-50503CF-040.0M Connor-Winfield OH300 OCXO 40MHz CMOS 3.3V ±5ppb 0°C ~ 70°C
OH300-61003CF-025.0M Connor-Winfield OH300 OCXO 25MHz CMOS 3.3V ±10ppb -40°C ~ 85°C
OH300-61003CF-025.0M Connor-Winfield OH300 OCXO 25MHz CMOS 3.3V ±10ppb -40°C ~ 85°C
OH300-61003CF-025.0M Connor-Winfield OH300 OCXO 25MHz CMOS 3.3V ±10ppb -40°C ~ 85°C
DOCSC012F-040.0M Connor-Winfield DOCSC OCXO 40MHz LVCMOS 3.3V ±10ppb -40°C ~ 85°C
OH300-50503CF-050.0M Connor-Winfield OH300 OCXO 50MHz CMOS 3.3V ±5ppb 0°C ~ 70°C
OH300-50503CF-050.0M Connor-Winfield OH300 OCXO 50MHz CMOS 3.3V ±5ppb 0°C ~ 70°C
OH300-50503CF-050.0M Connor-Winfield OH300 OCXO 50MHz CMOS 3.3V ±5ppb 0°C ~ 70°C
OH300-61003CF-050.0M Connor-Winfield OH300 OCXO 50MHz CMOS 3.3V ±10ppb -40°C ~ 85°C
OH300-61003CF-050.0M Connor-Winfield OH300 OCXO 50MHz CMOS 3.3V ±10ppb -40°C ~ 85°C
OH300-61003CF-050.0M Connor-Winfield OH300 OCXO 50MHz CMOS 3.3V ±10ppb -40°C ~ 85°C
