Connor-Winfield宣布推出符合ITU-T G.8262的新TCXO6G晶振,TL602-010.0M
Connor-Winfield宣布推出符合ITU-T G.8262的新TCXO6G晶振,TL602-010.0M,伊利诺伊州奥罗拉–TL602和ML602是温度补偿晶体振荡器（TCXO晶振）6G晶振型号，专门设计用于与0.1Hz配合使用（更高）滤波器带宽，符合基于T1的层次结构规范如ITU-TG.8262选项1和2ECC以及ITU-TG.813选项1和2SEC，用于Sonet、IEEE1588和同步以太网的第3层。ConnorWinfield晶振的TCXO生产线利用模拟温度补偿，具有出色的短期稳定性特性。TL602和ML602这两款TCXO在工业温度范围为-40至+85℃。它们也是小型的出色频率产品的参考选择例如蜂窝网络、无线应用设备和仪器仪表应用。
Connor-Winfield宣布推出符合ITU-T G.8262的新TCXO6G晶振,TL602-010.0M
特征：
•可用频率为10MHz、12.8MHz、19.2MHz、19.44MHz、20MHz和24.576MHz。
•LVCMOS或削波正弦波
•固定输出或电压控制
•符合在.1Hz带宽下测量的MTIE和TDEV模板
•在整个工业温度范围内具有280ppb峰峰值温度稳定性。
•在12kHz-20MHz频段内低于300ps的抖动性能
•使用精度为±4.6ppm
•完全符合ROHS和REACH标准
•7x5毫米（TL602）或5x3.2毫米（ML602）封装选项6G晶振
| 原厂代码 | 品牌 | 型号 | 频率 | 输出 | 电压 | 频率稳定度 | 工作温度 |
| TB522-100.0M | Connor-Winfield | TB | 100MHz | LVCMOS | 3.3V | ±1ppm | 0°C ~ 70°C |
| TB522-100.0M | Connor-Winfield | TB | 100MHz | LVCMOS | 3.3V | ±1ppm | 0°C ~ 70°C |
| TB522-100.0M | Connor-Winfield | TB | 100MHz | LVCMOS | 3.3V | ±1ppm | 0°C ~ 70°C |
| T200F-040.0M | Connor-Winfield | T200 | 40MHz | LVCMOS | 3.3V | ±200ppb | -40°C ~ 85°C |
| T200F-040.0M | Connor-Winfield | T200 | 40MHz | LVCMOS | 3.3V | ±200ppb | -40°C ~ 85°C |
| T200F-040.0M | Connor-Winfield | T200 | 40MHz | LVCMOS | 3.3V | ±200ppb | -40°C ~ 85°C |
| TB602-038.88M | Connor-Winfield | TB | 38.88MHz | LVCMOS | 3.3V | ±280ppb | -40°C ~ 85°C |
| TB602-038.88M | Connor-Winfield | TB | 38.88MHz | LVCMOS | 3.3V | ±280ppb | -40°C ~ 85°C |
| TB602-038.88M | Connor-Winfield | TB | 38.88MHz | LVCMOS | 3.3V | ±280ppb | -40°C ~ 85°C |
| TB512-052.0M | Connor-Winfield | TB | 52MHz | LVCMOS | 3.3V | ±500ppb | 0°C ~ 70°C |
| TB512-052.0M | Connor-Winfield | TB | 52MHz | LVCMOS | 3.3V | ±500ppb | 0°C ~ 70°C |
| TB512-052.0M | Connor-Winfield | TB | 52MHz | LVCMOS | 3.3V | ±500ppb | 0°C ~ 70°C |
| TB522-080.0M | Connor-Winfield | TB | 80MHz | LVCMOS | 3.3V | ±1ppm | 0°C ~ 70°C |
| TB522-080.0M | Connor-Winfield | TB | 80MHz | LVCMOS | 3.3V | ±1ppm | 0°C ~ 70°C |
| TB522-080.0M | Connor-Winfield | TB | 80MHz | LVCMOS | 3.3V | ±1ppm | 0°C ~ 70°C |
| TB524-100.0M | Connor-Winfield | TB | 100MHz | LVCMOS | 3.3V | ±1ppm | 0°C ~ 70°C |
| TB524-100.0M | Connor-Winfield | TB | 100MHz | LVCMOS | 3.3V | ±1ppm | 0°C ~ 70°C |
| TB524-100.0M | Connor-Winfield | TB | 100MHz | LVCMOS | 3.3V | ±1ppm | 0°C ~ 70°C |
| TB512-050.0M | Connor-Winfield | TB | 50MHz | LVCMOS | 3.3V | ±500ppb | 0°C ~ 70°C |
| TB512-050.0M | Connor-Winfield | TB | 50MHz | LVCMOS | 3.3V | ±500ppb | 0°C ~ 70°C |
| TB512-050.0M | Connor-Winfield | TB | 50MHz | LVCMOS | 3.3V | ±500ppb | 0°C ~ 70°C |
| TL602-024.576M | Connor-Winfield | TL602 | 24.576MHz | LVCMOS | 3.3V | ±140ppb | -40°C ~ 85°C |
| TL602-024.576M | Connor-Winfield | TL602 | 24.576MHz | LVCMOS | 3.3V | ±140ppb | -40°C ~ 85°C |
| TL602-024.576M | Connor-Winfield | TL602 | 24.576MHz | LVCMOS | 3.3V | ±140ppb | -40°C ~ 85°C |
| TB602-049.152M | Connor-Winfield | TB | 49.152MHz | LVCMOS | 3.3V | ±280ppb | -40°C ~ 85°C |
| TB602-049.152M | Connor-Winfield | TB | 49.152MHz | LVCMOS | 3.3V | ±280ppb | -40°C ~ 85°C |
| TB602-049.152M | Connor-Winfield | TB | 49.152MHz | LVCMOS | 3.3V | ±280ppb | -40°C ~ 85°C |
| T200F-020.0M | Connor-Winfield | T200 | 20MHz | LVCMOS | 3.3V | ±200ppb | -40°C ~ 85°C |
| T200F-020.0M | Connor-Winfield | T200 | 20MHz | LVCMOS | 3.3V | ±200ppb | -40°C ~ 85°C |
| T200F-020.0M | Connor-Winfield | T200 | 20MHz | LVCMOS | 3.3V | ±200ppb | -40°C ~ 85°C |
| T200F-024.576M | Connor-Winfield | T200 | 24.576MHz | LVCMOS | 3.3V | ±200ppb | -40°C ~ 85°C |
| T200F-024.576M | Connor-Winfield | T200 | 24.576MHz | LVCMOS | 3.3V | ±200ppb | -40°C ~ 85°C |
| T200F-024.576M | Connor-Winfield | T200 | 24.576MHz | LVCMOS | 3.3V | ±200ppb | -40°C ~ 85°C |
| T200F-010.0M | Connor-Winfield | T200 | 10MHz | LVCMOS | 3.3V | ±200ppb | -40°C ~ 85°C |
| T200F-010.0M | Connor-Winfield | T200 | 10MHz | LVCMOS | 3.3V | ±200ppb | -40°C ~ 85°C |
| T200F-010.0M | Connor-Winfield | T200 | 10MHz | LVCMOS | 3.3V | ±200ppb | -40°C ~ 85°C |
| TL602-020.0M | Connor-Winfield | TL602 | 20MHz | LVCMOS | 3.3V | ±140ppb | -40°C ~ 85°C |
| TL602-020.0M | Connor-Winfield | TL602 | 20MHz | LVCMOS | 3.3V | ±140ppb | -40°C ~ 85°C |
| TL602-020.0M | Connor-Winfield | TL602 | 20MHz | LVCMOS | 3.3V | ±140ppb | -40°C ~ 85°C |
| TB514-052.0M | Connor-Winfield | TB | 52MHz | LVCMOS | 3.3V | ±500ppb | 0°C ~ 70°C |
| TB514-052.0M | Connor-Winfield | TB | 52MHz | LVCMOS | 3.3V | ±500ppb | 0°C ~ 70°C |
| TB514-052.0M | Connor-Winfield | TB | 52MHz | LVCMOS | 3.3V | ±500ppb | 0°C ~ 70°C |
| TB514-054.0M | Connor-Winfield | TB | 54MHz | LVCMOS | 3.3V | ±500ppb | 0°C ~ 70°C |
| TB514-054.0M | Connor-Winfield | TB | 54MHz | LVCMOS | 3.3V | ±500ppb | 0°C ~ 70°C |
| TB514-054.0M | Connor-Winfield | TB | 54MHz | LVCMOS | 3.3V | ±500ppb | 0°C ~ 70°C |
| TB524-080.0M | Connor-Winfield | TB | 80MHz | LVCMOS | 3.3V | ±1ppm | 0°C ~ 70°C |
| TB524-080.0M | Connor-Winfield | TB | 80MHz | LVCMOS | 3.3V | ±1ppm | 0°C ~ 70°C |
| TB524-080.0M | Connor-Winfield | TB | 80MHz | LVCMOS | 3.3V | ±1ppm | 0°C ~ 70°C |
| TB512-054.0M | Connor-Winfield | TB | 54MHz | LVCMOS | 3.3V | ±500ppb | 0°C ~ 70°C |
| TB512-054.0M | Connor-Winfield | TB | 54MHz | LVCMOS | 3.3V | ±500ppb | 0°C ~ 70°C |
| TB512-054.0M | Connor-Winfield | TB | 54MHz | LVCMOS | 3.3V | ±500ppb | 0°C ~ 70°C |
| PM113-250.0M | Connor-Winfield | PM | 250MHz | LVPECL | 3.3V | ±25ppm | 0°C ~ 70°C |
| PM113-200.0M | Connor-Winfield | PM | 200MHz | LVPECL | 3.3V | ±25ppm | 0°C ~ 70°C |
| PM113-466.56M | Connor-Winfield | PM | 466.56MHz | LVPECL | 3.3V | ±25ppm | 0°C ~ 70°C |
| V803-074.1758M | Connor-Winfield | V803 | 74.1758MHz | LVCMOS | 3.3V | ±15ppm | 0°C ~ 70°C |
| V803-074.25M | Connor-Winfield | V803 | 74.25MHz | LVCMOS | 3.3V | ±15ppm | 0°C ~ 70°C |
| TB514-050.0M | Connor-Winfield | TB | 50MHz | LVCMOS | 3.3V | ±500ppb | 0°C ~ 70°C |
| TB514-050.0M | Connor-Winfield | TB | 50MHz | LVCMOS | 3.3V | ±500ppb | 0°C ~ 70°C |
| TB514-050.0M | Connor-Winfield | TB | 50MHz | LVCMOS | 3.3V | ±500ppb | 0°C ~ 70°C |
| V803-100.0M | Connor-Winfield | V803 | 100MHz | LVCMOS | 3.3V | ±15ppm | 0°C ~ 70°C |
| V803-125.0M | Connor-Winfield | V803 | 125MHz | LVCMOS | 3.3V | ±15ppm | 0°C ~ 70°C |
| X502-622.08M | Connor-Winfield | X502 | 622.08MHz | LVDS | 3.3V | - | 0°C ~ 70°C |
| PM113-622.08M | Connor-Winfield | PM | 622.08MHz | LVPECL | 3.3V | ±25ppm | 0°C ~ 70°C |
| PM113-161.1328M | Connor-Winfield | PM | 161.1328MHz | LVPECL | 3.3V | ±25ppm | 0°C ~ 70°C |
| PM113-311.04M | Connor-Winfield | PM | 311.04MHz | LVPECL | 3.3V | ±25ppm | 0°C ~ 70°C |
| PM113-625.0M | Connor-Winfield | PM | 625MHz | LVPECL | 3.3V | ±25ppm | 0°C ~ 70°C |
| TB602-050.0M | Connor-Winfield | TB | 50MHz | LVCMOS | 3.3V | ±280ppb | -40°C ~ 85°C |
| TB602-050.0M | Connor-Winfield | TB | 50MHz | LVCMOS | 3.3V | ±280ppb | -40°C ~ 85°C |
| TB602-050.0M | Connor-Winfield | TB | 50MHz | LVCMOS | 3.3V | ±280ppb | -40°C ~ 85°C |
| PM113-161.1328M-T | Connor-Winfield | PM | 161.1328MHz | LVPECL | 3.3V | ±25ppm | 0°C ~ 70°C |
| PM113-200.0M-T | Connor-Winfield | PM | 200MHz | LVPECL | 3.3V | ±25ppm | 0°C ~ 70°C |
| PM113-212.5M-T | Connor-Winfield | PM | 212.5MHz | LVPECL | 3.3V | ±25ppm | 0°C ~ 70°C |
| PM113-250.0M-T | Connor-Winfield | PM | 250MHz | LVPECL | 3.3V | ±25ppm | 0°C ~ 70°C |
| PM113-311.04M-T | Connor-Winfield | PM | 311.04MHz | LVPECL | 3.3V | ±25ppm | 0°C ~ 70°C |
| PM113-312.5M-T | Connor-Winfield | PM | 312.5MHz | LVPECL | 3.3V | ±25ppm | 0°C ~ 70°C |
| PM113-318.75M-T | Connor-Winfield | PM | 318.75MHz | LVPECL | 3.3V | ±25ppm | 0°C ~ 70°C |
| PM113-466.56M-T | Connor-Winfield | PM | 466.56MHz | LVPECL | 3.3V | ±25ppm | 0°C ~ 70°C |
| PM113-622.08M-T | Connor-Winfield | PM | 622.08MHz | LVPECL | 3.3V | ±25ppm | 0°C ~ 70°C |
| PM113-625.0M-T | Connor-Winfield | PM | 625MHz | LVPECL | 3.3V | ±25ppm | 0°C ~ 70°C |
| PM113-212.5M | Connor-Winfield | PM | 212.5MHz | LVPECL | 3.3V | ±25ppm | 0°C ~ 70°C |
| PM113-312.5M | Connor-Winfield | PM | 312.5MHz | LVPECL | 3.3V | ±25ppm | 0°C ~ 70°C |
| PM113-318.75M | Connor-Winfield | PM | 318.75MHz | LVPECL | 3.3V | ±25ppm | 0°C ~ 70°C |
| TB604-050.0M | Connor-Winfield | TB | 50MHz | LVCMOS | 3.3V | ±280ppb | -40°C ~ 85°C |
| TB612-052.0M | Connor-Winfield | TB | 52MHz | LVCMOS | 3.3V | ±500ppb | -40°C ~ 85°C |
| TB612-054.0M | Connor-Winfield | TB | 54MHz | LVCMOS | 3.3V | ±500ppb | -40°C ~ 85°C |
| TB622-080.0M | Connor-Winfield | TB | 80MHz | LVCMOS | 3.3V | ±1ppm | -40°C ~ 85°C |
| TB622-100.0M | Connor-Winfield | TB | 100MHz | LVCMOS | 3.3V | ±1ppm | -40°C ~ 85°C |
| TB614-050.0M | Connor-Winfield | TB | 50MHz | LVCMOS | 3.3V | ±500ppb | -40°C ~ 85°C |
| TB614-052.0M | Connor-Winfield | TB | 52MHz | LVCMOS | 3.3V | ±500ppb | -40°C ~ 85°C |
| TB614-054.0M | Connor-Winfield | TB | 54MHz | LVCMOS | 3.3V | ±500ppb | -40°C ~ 85°C |
| TB624-080.0M | Connor-Winfield | TB | 80MHz | LVCMOS | 3.3V | ±1ppm | -40°C ~ 85°C |
| TB624-100.0M | Connor-Winfield | TB | 100MHz | LVCMOS | 3.3V | ±1ppm | -40°C ~ 85°C |
| TB612-050.0M | Connor-Winfield | TB | 50MHz | LVCMOS | 3.3V | ±500ppb | -40°C ~ 85°C |
| V702-155.52M | Connor-Winfield | V702 | 155.52MHz | LVPECL | 3.3V | ±50ppm | 0°C ~ 70°C |
| V702-156.25M | Connor-Winfield | V702 | 156.25MHz | LVPECL | 3.3V | ±50ppm | 0°C ~ 70°C |
| TFLD546-012.8M | Connor-Winfield | TFLD546 | 12.8MHz | LVCMOS | 3.3V | - | 0°C ~ 70°C |
| TFLD546-020.0M | Connor-Winfield | TFLD546 | 20MHz | LVCMOS | 3.3V | - | 0°C ~ 70°C |
| TVB602-050.0M | Connor-Winfield | TVB | 50MHz | LVCMOS | 3.3V | ±280ppb | -40°C ~ 85°C |
| XH722-032.0M | Connor-Winfield | XH7 | 32MHz | LVCMOS | 2.5V | ±50ppm | -55°C ~ 125°C |
| V802-074.1758M | Connor-Winfield | V802 | 74.1758MHz | LVCMOS | 3.3V | ±50ppm | 0°C ~ 70°C |
| V802-074.25M | Connor-Winfield | V802 | 74.25MHz | LVCMOS | 3.3V | ±50ppm | 0°C ~ 70°C |
| V802-100.0M | Connor-Winfield | V802 | 100MHz | LVCMOS | 3.3V | ±50ppm | 0°C ~ 70°C |
| V802-125.0M | Connor-Winfield | V802 | 125MHz | LVCMOS | 3.3V | ±50ppm | 0°C ~ 70°C |
