M3028S00970.656000,M3028差分晶振,VCXO有源压控晶振
M3028S00970.656000晶振的核心竞争力在于差分输出抗干扰能力与VCXO压控可调特性的协同作用:相较于单端输出晶振,其差分输出接口(以LVPECL差分晶体振荡器为例,输出摆幅350mV~850mV,共模电压1.3V~2.0V)可通过差分信号传输原理抵消传输路径上的共模噪声(如电源噪声,电磁辐射干扰),时钟信号信噪比(SNR)提升30%以上,即使在长距离传输(如PCB板上传输距离≥20cm)或多模块密集布局场景中,仍能保持信号完整性,避免时序错乱.而VCXO压控功能则赋予时钟信号"动态校准”能力:当设备因环境温度变化(如户外通信基站昼夜温差),电源电压波动导致频率偏移时,外部控制系统可通过实时调整控制电压,将频率偏差修正至±1ppm以内,确保设备时钟与系统基准时钟(如GPS同步时钟)保持严格同步,这一特性对需要长期稳定运行的通信设备(如5G核心网传输设备),精密测量仪器(如矢量网络分析仪)至关重要.此外,产品还具备低相位噪声特性(典型值-120dBc/Hz@1kHz偏移,-145dBc/Hz@100kHz偏移),可减少时钟信号对射频模块的干扰,提升设备整体性能.
M3028S00970.656000,M3028差分晶振,VCXO有源压控晶振
| 原厂型号 Originalmodel： |
          M2532S135 7.372800
|
品牌brand： |
   MTRONPTI麦特伦皮
|
| Manufacturer品牌 |
  MTRONPTI麦特伦皮
|
OperatingTemperature温度 | -40℃ to +85℃ |
| Series型号 |
   M2532高密度晶振
|
Current-Supply(Max) | - |
| Type类型 | XO (Standard) | PackageHeight高度 | 1.2MM |
| Frequency频率 |
  7.3728M
|
Termination 脚位 |
 4 pad
|
| 输出方式 Output： | HCMOS | PackageType 封装类型 | 4-SMD |
| Voltage-Supply电压 | 3.3V | Packaging 包装 | TapeandReel |
| FrequencyStability频率稳定度 |
      ±50 ppm
|
安装方式 Installation： | Surfacemount |
| Size/Dimension尺寸 | 2.5 X 3.2 mm | 最小包装数MPQ： | 3000 |
M3028S00970.656000,M3028差分晶振,VCXO有源压控晶振
M3028S00970.656000,M3028差分晶振,VCXO有源压控晶振
| M220168MPJ 156.250000 | M220x | XO | ±20 ppm | 156.25 | ±20 ppm | ±3 ppm | 9.0 X 14.0 mm | -20°C to +70°C |
| MH13FAD-R 16.000000 | M3H and MH | XO | ±100 ppm | 16 | ±100 ppm | ±2 ppm | 8-Pin DIP | 0?C to +70?C |
| 1698-065 18.600000 | MHO+ | XO | ±25 ppm | 18.6 | ±10 ppm | ±2 ppm | 14 Pin DIP | -40?C to +85?C |
| 1674-005 44.736000 | MV3 and MV5 | VCXO | ±50 ppm | 44.736 | ±50 ppm | ±0.5 ppm | 5.0 x 7.0 mm | -40°C to +85°C |
| 1674-007 19.440000 | MV3 and MV5 | VCXO | ±50 ppm | 19.44 | ±50 ppm | ±0.5 ppm | 5.0 x 7.0 mm | -40°C to +85°C |
| 1674-008 32.768000 | MV3 and MV5 | VCXO | ±50 ppm | 32.768 | ±50 ppm | ±0.5 ppm | 5.0 x 7.0 mm | -40°C to +85°C |
| 1674-009 25.000000 | MV3 and MV5 | VCXO | ±50 ppm | 25 | ±50 ppm | ±0.5 ppm | 5.0 x 7.0 mm | -40°C to +85°C |
| 1674-013 38.880000 | MV3 and MV5 | VCXO | ±50 ppm | 38.88 | ±50 ppm | ±0.5 ppm | 5.0 x 7.0 mm | -40°C to +85°C |
| XO9085-002 | XO9085 | OCXO | ±100 ppb | 100 | ±100 ppb | ±0.5 ppm | Rackmount | 0?C to +50?C |
| XO9085-004 | XO9085 | OCXO | ±100 ppb | 100 | ±100 ppb | ±0.5 ppm | Rackmount | -40?C to +75?C |
| M60532JCN 25.000000 | M6053 and M6054 | TCXO | ±1 ppm | 25 | ±1 ppm | ±1 ppm | 3.2 X 5.0 mm | -40?C to +85?C |
| M60532JSN 10.000000 | M6053 and M6054 | TCXO | ±1 ppm | 10 | ±1 ppm | ±1 ppm | 3.2 X 5.0 mm | -40?C to +85?C |
| M6053S023 32.000000 | M6053 and M6054 | TCXO | ±2.5 ppm | 32 | ±1 ppm | ±1 ppm | 3.2 X 5.0 mm | -40?C to +85?C |
| M6053S036 50.000000 | M6053 and M6054 | TCXO | ±2 ppm | 50 | ±1.5 ppm | ±1 ppm | 3.2 X 5.0 mm | -40?C to +85?C |
| M60552JSN 48.000000 | M6055 and M6056 | TCXO | ±1 ppm | 48 | ±1 ppm | ±1 ppm | 2.5 X 2.0 mm | -40?C to +85?C |
| M6055S014 10.000000 | M6055 and M6056 | TCXO | ±2 ppm | 10 | ±2 ppm | ±1 ppm | 2.5 X 2.0 mm | -30?C to +75?C |
| M6056HGSN 26.000000 | M6055 and M6056 | VCTCXO | ±0.5 ppm | 26 | ±0.5 ppm | ±1 ppm | 2.5 X 3.2 mm | -30?C to +85?C |
| M60642GSN 40.000000 | M6064 and M6065 | TCXO | ±0.5 ppm | 40 | ±0.5 ppm | ±1 ppm | 2.5 X 2.0 mm | -40?C to +85?C |
| M6064S031 20.000000 | M6064 and M6065 | TCXO | ±1 ppm | 20 | ±1 ppm | ±1 ppm | 2.5 X 2.0 mm | -40?C to +85?C |
| 60103-339-R 12.000000 | M3H and MH | XO | ±100 ppm | 12 | ±100 ppm | ±2 ppm | 8-Pin Gull-Wing | -55?C to +105?C |
| 60110-239-R 1.000000 | M3H and MH | XO | ±100 ppm | 1 | ±100 ppm | ±2 ppm | 8-Pin Gull-Wing | -40?C to +85?C |
| 60153-139-R 24.576000 | M3H and MH | XO | ±100 ppm | 24.576 | ±100 ppm | ±2 ppm | 8-Pin Gull-Wing | 0?C to +70?C |
| 60184-269-R 18.432000 | M3H and MH | XO | ±25 ppm | 18.432 | ±25 ppm | ±2 ppm | 8-Pin Gull-Wing | -40?C to +70?C |
| M61612GTSN 10.000000 | M616x | VCTCXO | ±0.5 ppm | 10 | ±1 ppm | NS | 5.0 x 7.0 mm | -40°C to +85°C |
| M61612JFCN 20.000000 | M616x | TCXO | ±1 ppm | 20 | ±1 ppm | NS | 5.0 x 7.0 mm | -40°C to +85°C |
| M61612JTCN 10.000000 | M616x | VCTCXO | ±1 ppm | 10 | ±1 ppm | NS | 5.0 x 7.0 mm | -40°C to +85°C |
| M61612LTCN 10.000000 | M616x | VCTCXO | ±4.6 ppm | 10 | ±1 ppm | NS | 5.0 x 7.0 mm | -40°C to +85°C |
| M61612MFCN 10.000000 | M616x | TCXO | ±0.2 ppm | 10 | ±1 ppm | NS | 5.0 x 7.0 mm | -40°C to +85°C |
| M61613LFSN 50.000000 | M616x | TCXO | ±4.6 ppm | 50 | ±1 ppm | NS | 5.0 x 7.0 mm | -55°C to +105°C |
| M61616LTCN 10.000000 | M616x | VCTCXO | ±4.6 ppm | 10 | ±1 ppm | NS | 5.0 x 7.0 mm | -20°C to +70°C |
| M61641GFCN 10.000000 | M616x | TCXO | ±0.5 ppm | 10 | ±1 ppm | NS | 5.0 x 7.0 mm | 0°C to +70°C |
| M61641GFCN 40.000000 | M616x | TCXO | ±0.5 ppm | 40 | ±1 ppm | NS | 5.0 x 7.0 mm | 0°C to +70°C |
| M61642GFCN 24.000000 | M616x | TCXO | ±0.5 ppm | 24 | ±1 ppm | NS | 5.0 x 7.0 mm | -40°C to +85°C |
| M61642GFSN 20.000000 | M616x | TCXO | ±0.5 ppm | 20 | ±1 ppm | NS | 5.0 x 7.0 mm | -40°C to +85°C |
| M61642GTSN 40.000000 | M616x | VCTCXO | ±0.5 ppm | 40 | ±1 ppm | NS | 5.0 x 7.0 mm | -40°C to +85°C |
| M61642JFCN 20.000000 | M616x | TCXO | ±1 ppm | 20 | ±1 ppm | NS | 5.0 x 7.0 mm | -40°C to +85°C |
| M61642JFCN 50.000000 | M616x | TCXO | ±1 ppm | 50 | ±1 ppm | NS | 5.0 x 7.0 mm | -40°C to +85°C |
| M61642JFSN 10.000000 | M616x | TCXO | ±1 ppm | 10 | ±1 ppm | NS | 5.0 x 7.0 mm | -40°C to +85°C |
| M61642JTSN 9.600000 | M616x | VCTCXO | ±1 ppm | 9.6 | ±1 ppm | NS | 5.0 x 7.0 mm | -40°C to +85°C |
| M61642KFSN 10.000000 | M616x | TCXO | ±2 ppm | 10 | ±1 ppm | NS | 5.0 x 7.0 mm | -40°C to +85°C |
| M61646PTCN 50.000000 | M616x | VCTCXO | ±0.3 ppm | 50 | ±1 ppm | NS | 5.0 x 7.0 mm | -20°C to +70°C |
| M61652GFCN 10.000000 | M616x | TCXO | ±0.5 ppm | 10 | ±1 ppm | ±1 ppm | 5.0 x 7.0 mm | -40°C to +85°C |
| M61652GFSN 10.000000 | M616x | TCXO | ±0.5 ppm | 10 | ±1 ppm | ±1 ppm | 5.0 x 7.0 mm | -40°C to +85°C |
| M61812GTSN 10.000000 | M168x | VCTCXO | ±0.5 ppm | 10 | ±1 ppm | ±1 ppm | 3.2 X 5.0 mm | -40°C to +85°C |
| M61812MFSN 16.384000 | M618x | TCXO | ±0.2 ppm | 16.384 | ±1 ppm | ±1 ppm | 3.2 X 5.0 mm | -40°C to +85°C |
| M61812MTSN 16.384000 | M618x | VCTCXO | ±0.2 ppm | 16.384 | ±1 ppm | ±1 ppm | 3.2 X 5.0 mm | -40°C to +85°C |
| M61812PFCN 25.000000 | M168x | TCXO | ±0.3 ppm | 25 | ±1 ppm | ±1 ppm | 3.2 X 5.0 mm | -40°C to +85°C |
| M61812PTCN 24.576000 | M168x | VCTCXO | ±0.3 ppm | 24.576 | ±1 ppm | ±1 ppm | 3.2 X 5.0 mm | -40°C to +85°C |
| M61816GFCN 50.000000 | M168x | TCXO | ±0.5 ppm | 50 | ±1 ppm | ±1 ppm | 3.2 X 5.0 mm | -20°C to +70°C |
| M61816PTCN 50.000000 | M168x | VCTCXO | ±0.3 ppm | 50 | ±1 ppm | ±1 ppm | 3.2 X 5.0 mm | -20°C to +70°C |
| M6181S020 32.000000 | M618x | VCTCXO | ±0.28 ppm | 32 | ±1 ppm | ±0.5 ppm | 5.0 x 7.0 mm | -40°C to +85°C |
| M61822PFSN 8.192000 | M168x | TCXO | ±0.3 ppm | 8.192 | ±1 ppm | ±1 ppm | 3.2 X 5.0 mm | -40°C to +85°C |
| HPO-310 66.000000 | HPO | XO | ±5 ppm | 66 | ±5 ppm | NS | 5.0 x 7.0 mm | -55?C to +125?C |
| HPO-310 77.760000 | HPO | XO | ±5 ppm | 77.76 | ±5 ppm | NS | 5.0 x 7.0 mm | -55?C to +125?C |
| HPO-311 112.500000 | HPO | XO | ±5 ppm | 112.5 | ±5 ppm | NS | 5.0 x 7.0 mm | -55?C to +125?C |
| HPO-311 25.000000 | HPO | XO | ±5 ppm | 25 | ±5 ppm | NS | 5.0 x 7.0 mm | -55?C to +125?C |
| HPO-311 62.208000 | HPO | XO | ±5 ppm | 62.208 | ±5 ppm | NS | 5.0 x 7.0 mm | -55?C to +125?C |
| HPO-320 66.000000 | HPO | XO | ±5 ppm | 66 | ±5 ppm | NS | 5.0 x 7.0 mm | -55?C to +125?C |
| HPO-320 77.760000 | HPO | XO | ±5 ppm | 77.76 | ±5 ppm | NS | 5.0 x 7.0 mm | -55?C to +125?C |
| HPO-321 112.500000 | HPO | XO | ±5 ppm | 112.5 | ±5 ppm | NS | 5.0 x 7.0 mm | -55?C to +125?C |
