为您找到第一年老化低的晶振,ECS-240-20-28A-TR晶振

来源：亿金电子查看手机网址

扫一扫!

扫一扫!

浏览：- 发布日期：2023-06-17 16:50:14【大中小】

分享到：

为您找到第一年老化低的晶振,ECS-240-20-28A-TR晶振，当石英振动时，该谐振表面的结构松弛，从而导致频率偏移。所有晶振在生命的最初几年都必须处理这个问题。

ECS晶振公司的创新制造商团队开发了一种解决方案来解释这种固有频率偏移。但是，此解决方案不仅可以补偿偏移;它还适用于需要石英晶振振荡器的更广泛的创新应用。

ECS晶振公司的“B 系列”晶振（也称为“低第一年老化”表面贴装晶振）在小尺寸封装中提供极低的频率偏移。ECS晶振公司是包括石英晶体振荡器在内的计时解决方案的领先设计和工程公司，该产品的突破可确保您最新的工程壮举能够提供开箱即用的精确频率。

了解ECS公司的“B系列”晶振振荡器

为您找到第一年老化低的晶振,ECS-240-20-28A-TR晶振，“B系列”石英晶振振荡器背后的概念和技术源自烤箱控制的晶振振荡器（OCXO）制造工艺，其中对这些组件进行测试以确保其在特定条件下运行。与在扩展温度下测试产品功能的OCXO测试非常相似，“B系列”晶振是预老化和预应力的，因此当该晶振用作电路板中的石英振荡器时，松弛（和频率偏移）已经发生。从本质上讲，ECS晶振公司的老化过程使该晶振在石英晶振振荡器电路中具有最佳性能。当您购买低第一年老化晶振时，您现在可以选择晶振振荡器频率，该频率不会偏移超出可用范围。晶振资料下载

“B系列”晶振振荡器的未来应用

考虑ECS晶振公司的“B系列”晶振，用于需要极小频率偏移的新兴技术和应用。

ECS晶振公司的“B 系列”晶振已在全球范围内应用于以下应用：

智慧城市基础设施，包括照明和信号

3D相机、虚拟现实和人工智能

大气卫星连接

ECS原厂编码	型号	频率	频率容差	频率偏差度	负载电容	工作温度
ECS-120-20-3X-EN-TR	CSM-3X	12MHz	±50ppm	±30ppm	20pF	-40°C ~ 85°C
ECS-120-20-3X-TR	CSM-3X	12MHz	±50ppm	±30ppm	20pF	-10°C ~ 70°C
ECS-122.8-20-3X-EN-TR	CSM-3X	12.288MHz	±50ppm	±30ppm	20pF	-40°C ~ 85°C
ECS-122.8-20-3X-TR	CSM-3X	12.288MHz	±50ppm	±30ppm	20pF	-10°C ~ 70°C
ECS-130-20-3X-EN-TR	CSM-3X	13MHz	±50ppm	±30ppm	20pF	-40°C ~ 85°C
ECS-130-20-3X-TR	CSM-3X	13MHz	±50ppm	±30ppm	20pF	-10°C ~ 70°C
ECS-135.6-20-3X-EN-TR	CSM-3X	13.56MHz	±50ppm	±30ppm	20pF	-40°C ~ 85°C
ECS-135.6-20-3X-TR	CSM-3X	13.56MHz	±50ppm	±30ppm	20pF	-10°C ~ 70°C
ECS-143-20-3X-EN-TR	CSM-3X	14.31818MHz	±50ppm	±30ppm	20pF	-40°C ~ 85°C
ECS-143-20-3X-TR	CSM-3X	14.31818MHz	±50ppm	±30ppm	20pF	-10°C ~ 70°C
ECS-147.4-20-3X-EN-TR	CSM-3X	14.7456MHz	±50ppm	±30ppm	20pF	-40°C ~ 85°C
ECS-147.4-20-3X-TR	CSM-3X	14.7456MHz	±50ppm	±30ppm	20pF	-10°C ~ 70°C
ECS-160-20-3X-EN-TR	CSM-3X	16MHz	±50ppm	±30ppm	20pF	-40°C ~ 85°C
ECS-160-20-3X-TR	CSM-3X	16MHz	±50ppm	±30ppm	20pF	-10°C ~ 70°C
ECS-184-20-3X-EN-TR	CSM-3X	18.432MHz	±50ppm	±30ppm	20pF	-40°C ~ 85°C
ECS-184-20-3X-TR	CSM-3X	18.432MHz	±50ppm	±30ppm	20pF	-10°C ~ 70°C
ECS-196.6-20-3X-EN-TR	CSM-3X	19.6608MHz	±50ppm	±30ppm	20pF	-40°C ~ 85°C
ECS-196.6-20-3X-TR	CSM-3X	19.6608MHz	±50ppm	±30ppm	20pF	-10°C ~ 70°C
ECS-200-20-3X-EN-TR	CSM-3X	20MHz	±50ppm	±30ppm	20pF	-40°C ~ 85°C
ECS-200-20-3X-TR	CSM-3X	20MHz	±50ppm	±30ppm	20pF	-10°C ~ 70°C
ECS-200-CDX-0914	CSM-3X	20MHz	±30ppm	±10ppm	10pF	-60°C ~ 105°C
ECS-245.7-20-3X-EN-TR	CSM-3X	24.576MHz	±50ppm	±30ppm	20pF	-40°C ~ 85°C
ECS-245.7-20-3X-TR	CSM-3X	24.576MHz	±50ppm	±30ppm	20pF	-10°C ~ 70°C
ECS-250-20-3X-EN-TR	CSM-3X	25MHz	±50ppm	±30ppm	20pF	-40°C ~ 85°C
ECS-250-20-3X-TR	CSM-3X	25MHz	±50ppm	±30ppm	20pF	-10°C ~ 70°C
ECS-270-20-3X-EN-TR	CSM-3X	27MHz	±50ppm	±30ppm	20pF	-40°C ~ 85°C
ECS-270-20-3X-TR	CSM-3X	27MHz	±50ppm	±30ppm	20pF	-10°C ~ 70°C
ECS-286.3-20-3X-EN-TR	CSM-3X	28.63636MHz	±50ppm	±30ppm	20pF	-40°C ~ 85°C
ECS-286.3-20-3X-TR	CSM-3X	28.63636MHz	±50ppm	±30ppm	20pF	-10°C ~ 70°C
ECS-300-20-3X-EN-TR	CSM-3X	30MHz	±50ppm	±30ppm	20pF	-40°C ~ 85°C
ECS-300-20-3X-TR	CSM-3X	30MHz	±50ppm	±30ppm	20pF	-10°C ~ 70°C
ECS-330-20-3X-EN-TR	CSM-3X	33MHz	±50ppm	±30ppm	20pF	-40°C ~ 85°C
ECS-330-20-3X-TR	CSM-3X	33MHz	±50ppm	±30ppm	20pF	-10°C ~ 70°C
ECS-400-20-3X-EN-TR	CSM-3X	40MHz	±50ppm	±30ppm	20pF	-40°C ~ 85°C
ECS-400-20-3X-TR	CSM-3X	40MHz	±50ppm	±30ppm	20pF	-10°C ~ 70°C
ECS-100-20-28A-TR	CSM-4A	10MHz	±50ppm	±30ppm	20pF	-10°C ~ 70°C
ECS-100-S-28A-TR	CSM-4A	10MHz	±50ppm	±30ppm	Series	-10°C ~ 70°C
ECS-110.5-20-28A-TR	CSM-4A	11.0592MHz	±50ppm	±30ppm	20pF	-10°C ~ 70°C
ECS-110.5-S-28A-TR	CSM-4A	11.0592MHz	±50ppm	±30ppm	Series	-10°C ~ 70°C
ECS-120-18-28A-TR	CSM-4A	12MHz	±50ppm	±30ppm	18pF	-10°C ~ 70°C
ECS-120-32-28A-TR	CSM-4A	12MHz	±50ppm	±30ppm	32pF	-10°C ~ 70°C
ECS-120-S-28A-TR	CSM-4A	12MHz	±50ppm	±30ppm	Series	-10°C ~ 70°C
ECS-122.8-20-28A-TR	CSM-4A	12.288MHz	±50ppm	±30ppm	20pF	-10°C ~ 70°C
ECS-143-20-28A-TR	CSM-4A	14.31818MHz	±50ppm	±30ppm	20pF	-10°C ~ 70°C
ECS-143-S-28A-TR	CSM-4A	14.31818MHz	±50ppm	±30ppm	Series	-10°C ~ 70°C
ECS-147.4-20-28A-TR	CSM-4A	14.7456MHz	±50ppm	±30ppm	20pF	-10°C ~ 70°C
ECS-147.4-S-28A-TR	CSM-4A	14.7456MHz	±50ppm	±30ppm	Series	-10°C ~ 70°C
ECS-160-20-28A-TR	CSM-4A	16MHz	±50ppm	±30ppm	20pF	-10°C ~ 70°C
ECS-160-S-28A-TR	CSM-4A	16MHz	±50ppm	±30ppm	Series	-10°C ~ 70°C
ECS-184-20-28A-TR	CSM-4A	18.432MHz	±50ppm	±30ppm	20pF	-10°C ~ 70°C
ECS-184-S-28A-TR	CSM-4A	18.432MHz	±50ppm	±30ppm	Series	-10°C ~ 70°C
ECS-200-20-28A-TR	CSM-4A	20MHz	±50ppm	±30ppm	20pF	-10°C ~ 70°C
ECS-200-S-28A-TR	CSM-4A	20MHz	±50ppm	±30ppm	Series	-10°C ~ 70°C
ECS-240-12-28A-TR	CSM-4A	24MHz	±50ppm	±30ppm	12pF	-10°C ~ 70°C
ECS-240-20-28A-TR	CSM-4A	24MHz	±50ppm	±30ppm	20pF	-10°C ~ 70°C
ECS-240-S-28A-TR	CSM-4A	24MHz	±50ppm	±30ppm	Series	-10°C ~ 70°C
ECS-245.7-20-28A-TR	CSM-4A	24.576MHz	±50ppm	±30ppm	20pF	-10°C ~ 70°C
ECS-250-20-28A-F-TR	CSM-4A	25MHz	±50ppm	±30ppm	20pF	-10°C ~ 70°C
ECS-35-17-28A-TR	CSM-4A	3.579545MHz	±50ppm	±30ppm	17pF	-10°C ~ 70°C
ECS-36-20-28A-TR	CSM-4A	3.6864MHz	±50ppm	±30ppm	20pF	-10°C ~ 70°C
ECS-40-20-28A-TR	CSM-4A	4MHz	±50ppm	±30ppm	20pF	-10°C ~ 70°C
ECS-49-20-28A-TR	CSM-4A	4.9152MHz	±50ppm	±30ppm	20pF	-10°C ~ 70°C
ECS-50-20-28A-TR	CSM-4A	5MHz	±50ppm	±30ppm	20pF	-10°C ~ 70°C
ECS-60-32-28A-TR	CSM-4A	6MHz	±50ppm	±30ppm	32pF	-10°C ~ 70°C
ECS-73-20-28A-TR	CSM-4A	7.3728MHz	±50ppm	±30ppm	20pF	-10°C ~ 70°C
ECS-80-16-28A-TR	CSM-4A	8MHz	±50ppm	±30ppm	16pF	-10°C ~ 70°C
ECS-98.3-20-28A-TR	CSM-4A	9.8304MHz	±50ppm	±30ppm	20pF	-10°C ~ 70°C
