能代替微型时钟晶振的GEYER微型振荡器
Alternative zum Uhrenquarz in Miniaturformat
Mit der Modellbezeichnung KXO-V93T bietet GEYER Crystal nun schon seit paar Jahrenerfolgreich Oszillatoren in einer bereits etablierten Miniaturisierung an.
Durch die kleinen Abmessungen von nur 1.6 x 1.2 mm und einer Bauh?he von 0.6 mm,ist dieser SMD-Oszillator im Frequenzbereich 1 – 80 MHz, bei geringem Stromverbrauch,besonders schock- und vibrationsfest.
Der Markt sucht zunehmend nach einer lternative zu einem Uhrenquarz (32,768kHz), die nicht nur die Bauform, sondern vor allem die technischen Parameter der herk?mmlichen Uhrenquarze überbieten soll.
Unsere Antwort darauf ist ein 32,768kHz Oszillator in der etablierten KXO-V93T Bauform, mit einer niedrigen Frequenztoleranz über den erweiterten -40° +85°C Temperaturbereich,niedrigen Jitterwerten, Tri-State Funktion und einer geringen Stromaufnahme.
Dieser Oszillator l?st die Stabilit?tsprobleme über den Temperatur- und Spannungsbereich der herk?mmlichen Uhrenquarze und wird nebst den g?ngigen Applikationen für Schwingquarze in allen Branchen eingesetzt, die diese Frequenz ben?tigen, z.B. Industrie Automation, Medical Equipment, IoT, M2M, Wireless Sensors, Sicherheitstechnik.
Der GEYER Electronic KXO-V93T 32,768kHz Oszillator ist ein zukunftsorientiertes Bauteil, das den stringentesten technischen Marktanforderungen gerecht wird: Frequenztoleranz,Anschwingzeit, Stromaufnahme.
微型时钟晶振的替代品
近年来，GEYER晶振已成功推出了 KXO-V93T 型微型振荡器。
这款频率范围为 1 - 80 MHz 的 SMD 振荡器尺寸小，仅为 1.6 x 1.2 mm，高度仅为 0.6 mm，特别耐冲击和振动，功耗低。
市场正在越来越多地寻找一种替代时钟晶体（32.768 kHz）的产品，这种产品不仅在设计上更胜一筹，最重要的是在技术参数上也优于传统的时钟晶体。
我们的答案是采用 KXO-V93T 成熟设计的 32.768kHz 振荡器，在扩展的 -40° +85°C 温度范围内具有低频率容差、低抖动值、三态功能和低功耗。
该振荡器解决了传统时钟晶体在温度和电压范围内的稳定性问题，除了振荡晶体的常规应用外，还可用于所有需要该频率的行业，如工业自动化、医疗设备、物联网、M2M、无线传感器、安全技术等。
GEYER Electronic KXO-V93T 32.768kHz 石英晶体振荡器是一款面向未来的元件，可满足最严格的市场技术要求： 频率公差、沉淀时间、电流消耗。
| 编码 | 描述 | 型号 | 尺寸 | 频率 | 负载 | 频率容差 |
| 12.87000 | 32.7680 kHz Quartz SMD KX-327VT | KX-327V | 1.25 | 1.05 | 0.5 mm | 32.768 kHz | 12.5 pF | ± 20 ppm |
| 12.87001 | 32.7680 kHz Quartz SMD KX-327VT | KX-327V | 1.25 | 1.05 | 0.5 mm | 32.768 kHz | 9 pF | ± 20 ppm |
| 12.87002 | 32.7680 kHz Quartz SMD KX-327VT | KX-327V | 1.25 | 1.05 | 0.5 mm | 32.768 kHz | 7 pF | ± 20 ppm |
| 12.87034 | 32.7680 kHz Quartz SMD KX-327RT | KX-327R | 2.0 | 1.2 | 0.6 mm | 32.768 kHz | 4 pF | ± 20 ppm |
| 12.87080 | 32.7680 kHz Quartz SMD KX-327NHT | KX-327NH | 3.2 | 1.5 | 0.8 mm | 32.768 kHz | 12.5 pF | ± 10 ppm |
| 12.87081 | 32.7680 kHz Quartz SMD KX-327NHT | KX-327NH | 3.2 | 1.5 | 0.8 mm | 32.768 kHz | 6 pF | ± 20 ppm |
| 12.87083 | 32.7680 kHz Quartz SMD KX-327NHT | KX-327NH | 3.2 | 1.5 | 0.8 mm | 32.768 kHz | 6 pF | ± 20 ppm |
| 12.87086 | 32.7680 kHz Quartz SMD KX-327NHT | KX-327NH | 3.2 | 1.5 | 0.8 mm | 32.768 kHz | 6 pF | ± 10 ppm |
| 12.87090 | 32.7680 kHz Quartz SMD KX-327NHT | KX-327NH | 3.2 | 1.5 | 0.8 mm | 32.768 kHz | 7 pF | ± 10 ppm |
| 12.87095 | 32.7680 kHz Quartz SMD KX-327NHT | KX-327NH | 3.2 | 1.5 | 0.8 mm | 32.768 kHz | 9 pF | ± 10 ppm |
| 12.87105 | 32,7680 kHz Quartz SMD KX-327ST | KX-327S | 8.2 | 3.8 | 2.5 mm | 32.768 kHz | 6 pF | ± 10 ppm |
| 12.87107 | 32.7680 kHz Quartz SMD KX-327S | KX-327S | 8.2 | 3.8 | 2.5 mm | 32.768 kHz | 12.5 pF | ± 20 ppm |
| 12.87109 | 32.7680 kHz Quartz SMD KX-327ST | KX-327S | 8.2 | 3.8 | 2.5 mm | 32.768 kHz | 12 pF | ± 15 ppm |
| 12.87110 | 32.7680 kHz Quartz SMD KX-327S | KX-327S | 8.2 | 3.8 | 2.5 mm | 32.768 kHz | 12.5 pF | ± 30 ppm |
| 12.87111 | 32.7680 kHz Quartz SMD KX-327ST | KX-327S | 8.2 | 3.8 | 2.5 mm | 32.768 kHz | 12.5 pF | ± 30 ppm |
| 12.87112 | 32.7680 kHz Quartz SMD KX-327S | KX-327S | 8.2 | 3.8 | 2.5 mm | 32.768 kHz | 12.5 pF | ± 20 ppm |
| 12.87113 | 32.7680 kHz Quartz SMD KX-327S | KX-327S | 8.2 | 3.8 | 2.5 mm | 32.768 kHz | 12.5 pF | ± 5.0 ppm |
| 12.87114 | 32.7680 kHz Quartz SMD KX-327ST | KX-327S | 8.2 | 3.8 | 2.5 mm | 32.768 kHz | 12.5 pF | ± 20 ppm |
| 12.87115 | 32.7680 kHz Quartz SMD KX-327ST | KX-327S | 8.2 | 3.8 | 2.5 mm | 32.768 kHz | 12.5 pF | ± 10 ppm |
| 12.87116 | 32.7680 kHz Quartz SMD KX-327S | KX-327S | 8.2 | 3.8 | 2.5 mm | 32.768 kHz | 12.5 pF | ± 10 ppm |
| 12.87118 | 32.7680 kHz Quartz SMD KX-327S | KX-327S | 8.2 | 3.8 | 2.5 mm | 32.768 kHz | 6 pF | ± 20 ppm |
| 12.87119 | 32.7680 kHz Quartz SMD KX-327ST | KX-327S | 8.2 | 3.8 | 2.5 mm | 32.768 kHz | 6 pF | ± 20 ppm |
| 12.87120 | 32.7680 kHz Quartz SMD KX-327XS | KX-327XS | 4.95 | 1.82 | 0.96 mm | 32.768 kHz | 12.5 pF | ± 30 ppm |
| 12.87121 | 32.7680 kHz Quartz SMD KX-327XST | KX-327XS | 4.95 | 1.82 | 0.96 mm | 32.768 kHz | 12.5 pF | ± 30 ppm |
| 12.87123 | 32.7680 kHz Quartz SMD KX-327XS | KX-327XS | 4.95 | 1.82 | 0.96 mm | 32.768 kHz | 6 pF | ± 30 ppm |
| 12.87126 | 32.7680 kHz Quartz SMD KX-327XS | KX-327XS | 4.95 | 1.82 | 0.96 mm | 32.768 kHz | 12.5 pF | ± 20 ppm |
| 12.87127 | 32.7680 kHz Quartz SMD KX-327XST | KX-327XS | 4.95 | 1.82 | 0.96 mm | 32.768 kHz | 6 pF | ± 30 ppm |
| 12.87128 | 32.7680 kHz Quartz SMD KX-327XST | KX-327XS | 4.95 | 1.82 | 0.96 mm | 32.768 kHz | 6 pF | ± 20 ppm |
| 12.87129 | 32.7680 kHz Quartz SMD KX-327XST | KX-327XS | 4.95 | 1.82 | 0.96 mm | 32.768 kHz | 12.5 pF | ± 20 ppm |
| 12.87130 | 32.7680 kHz Quartz SMD KX-327L | KX-327L | 7.0 | 1.5 | 1.4 mm | 32.768 kHz | 12.5 pF | ± 20 ppm |
| 12.87131 | 32.7680 kHz Quartz SMD KX-327LT | KX-327L | 7.0 | 1.5 | 1.4 mm | 32.768 kHz | 12.5 pF | ± 20 ppm |
| 12.87132 | 32.7680 kHz Quartz SMD KX-327L | KX-327L | 7.0 | 1.5 | 1.4 mm | 32.768 kHz | 7 pF | ± 20 ppm |
| 12.87133 | 32.7680 kHz Quartz SMD KX-327L | KX-327L | 7.0 | 1.5 | 1.4 mm | 32.768 kHz | 12.5 pF | ± 10 ppm |
| 12.87134 | 32.7680 kHz Quartz SMD KX-327L | KX-327L | 7.0 | 1.5 | 1.4 mm | 32.768 kHz | 7 pF | ± 10 ppm |
| 12.87135 | 32.7680 kHz Quartz SMD KX-327LT | KX-327L | 7.0 | 1.5 | 1.4 mm | 32.768 kHz | 7 pF | ± 20 ppm |
| 12.87136 | 32.7680 kHz Quartz SMD KX-327LT | KX-327L | 7.0 | 1.5 | 1.4 mm | 32.768 kHz | 12.5 pF | ± 10 ppm |
| 12.87137 | 32.7680 kHz Quartz SMD KX-327LT | KX-327L | 7.0 | 1.5 | 1.4 mm | 32.768 kHz | 9 pF | ± 20 ppm |
| 12.87138 | 32.7680 kHz Quartz SMD KX-327LT | KX-327L | 7.0 | 1.5 | 1.4 mm | 32.768 kHz | 12.5 pF | ± 5.0 ppm |
| 12.87139 | 32.7680 kHz Quartz SMD KX-327LT | KX-327L | 7.0 | 1.5 | 1.4 mm | 32.768 kHz | 7 pF | ± 10 ppm |
| 12.87143 | 32.7680 kHz Quartz SMD KX-327NHT | KX-327NH | 3.2 | 1.5 | 0.8 mm | 32.768 kHz | 9 pF | ± 20 ppm |
| 12.87144 | 32.7680 kHz Quartz SMD KX-327NHT | KX-327NH | 3.2 | 1.5 | 0.8 mm | 32.768 kHz | 7 pF | ± 5.0 ppm |
| 12.87145 | 32.7680 kHz Quartz SMD KX-327NHT | KX-327NH | 3.2 | 1.5 | 0.8 mm | 32.768 kHz | 12.5 pF | ± 20 ppm |
| 12.87146 | 32.7680 kHz Quartz SMD KX-327NHT | KX-327NH | 3.2 | 1.5 | 0.8 mm | 32.768 kHz | 9 pF | ± 10 ppm |
| 12.87147 | 32.7680 kHz Quartz SMD KX-327NHT | KX-327NH | 3.2 | 1.5 | 0.8 mm | 32.768 kHz | 7 pF | ± 10 ppm |
| 12.87148 | 32.7680 kHz Quartz SMD KX-327NHT | KX-327NH | 3.2 | 1.5 | 0.8 mm | 32.768 kHz | 7 pF | ± 20 ppm |
| 12.87149 | 32.7680 kHz Quartz SMD KX-327NHT | KX-327NH | 3.2 | 1.5 | 0.8 mm | 32.768 kHz | 9 pF | ± 20 ppm |
| 12.87150 | 32.7680 kHz Quartz SMD KX-327NHT | KX-327NH | 3.2 | 1.5 | 0.8 mm | 32.768 kHz | 12.5 pF | ± 20 ppm |
| 12.87151 | 32.7680 kHz Quartz SMD KX-327NHT | KX-327NH | 3.2 | 1.5 | 0.8 mm | 32.768 kHz | 9 pF | ± 30 ppm |
| 12.87152 | 32.7680 kHz Quartz SMD KX-327NHH | KX-327NH | 3.2 | 1.5 | 0.8 mm | 32.768 kHz | 12.5 pF | ± 20 ppm |
| 12.87153 | 32.7680 kHz Quartz SMD KX-327NHT | KX-327NH | 3.2 | 1.5 | 0.8 mm | 32.768 kHz | 7 pF | ± 20 ppm |
| 12.87155 | 32.7680 kHz Quartz SMD KX-327NHE | KX-327NH | 3.2 | 1.5 | 0.8 mm | 32.768 kHz | 12.5 pF | ± 30 ppm |
| 12.87157 | 32.7680 kHz Quartz SMD KX-327NHT | KX-327NH | 3.2 | 1.5 | 0.8 mm | 32.768 kHz | 12.5 pF | ± 5.0 ppm |
| 12.87158 | 32.7680 kHz Quartz SMD KX-327NHT | KX-327NH | 3.2 | 1.5 | 0.8 mm | 32.768 kHz | 12.5 pF | ± 10 ppm |
| 12.87159 | 32.7680 kHz Quartz SMD KX-327NHT | KX-327NH | 3.2 | 1.5 | 0.8 mm | 32.768 kHz | 12.5 pF | ± 20 ppm |
| 12.87160 | 32.7680 kHz Quartz SMD KX-327RT | KX-327R | 2.0 | 1.2 | 0.6 mm | 32.768 kHz | 12.5 pF | ± 20 ppm |
| 12.87161 | 32.7680 kHz Quartz SMD KX-327RT | KX-327R | 2.0 | 1.2 | 0.6 mm | 32.768 kHz | 12.5 pF | ± 5.0 ppm |
| 12.87163 | 32.7680 kHz Quartz SMD KX-327RT | KX-327R | 2.0 | 1.2 | 0.6 mm | 32.768 kHz | 7 pF | ± 20 ppm |
| 12.87164 | 32.7680 kHz Quartz SMD KX-327RT | KX-327R | 2.0 | 1.2 | 0.6 mm | 32.768 kHz | 9 pF | ± 30 ppm |
| 12.87165 | 32.7680 kHz Quartz SMD KX-327RT | KX-327R | 2.0 | 1.2 | 0.6 mm | 32.768 kHz | 9 pF | ± 20 ppm |
| 12.87166 | 32.7680 kHz Quartz SMD KX-327RF | KX-327R | 2.0 | 1.2 | 0.6 mm | 32.768 kHz | 12.5 pF | ± 20 ppm |
| 12.87167 | 32.7680 kHz Quartz SMD KX-327RT | KX-327R | 2.0 | 1.2 | 0.6 mm | 32.768 kHz | 12.5 pF | ± 10 ppm |
| 12.87168 | 32.7680 kHz Quartz SMD KX-327RF | KX-327R | 2.0 | 1.2 | 0.6 mm | 32.768 kHz | 9 pF | ± 20 ppm |
| 12.87169 | 32.7680 kHz Quartz SMD KX-327RT | KX-327R | 2.0 | 1.2 | 0.6 mm | 32.768 kHz | 9 pF | ± 10 ppm |
| 12.87170 | 32.7680 kHz Quartz SMD KX-327FT | KX-327F | 1.6 | 1.0 | 0.5 mm | 32.768 kHz | 12.5 pF | ± 20 ppm |
| 12.87171 | 32.7680 kHz Quartz SMD KX-327FT | KX-327F | 1.6 | 1.0 | 0.5 mm | 32.768 kHz | 12.5 pF | ± 10 ppm |
| 12.87172 | 32.7680 kHz Quartz SMD KX-327FT | KX-327F | 1.6 | 1.0 | 0.5 mm | 32.768 kHz | 9 pF | ± 20 ppm |
| 12.87173 | 32.7680 kHz Quartz SMD KX-327FT | KX-327F | 1.6 | 1.0 | 0.5 mm | 32.768 kHz | 9 pF | ± 10 ppm |
| 12.87174 | 32.7680 kHz Quartz SMD KX-327FT | KX-327F | 1.6 | 1.0 | 0.5 mm | 32.768 kHz | 7 pF | ± 20 ppm |
| 12.87175 | 32.7680 kHz Quartz SMD KX-327FT | KX-327F | 1.6 | 1.0 | 0.5 mm | 32.768 kHz | 7 pF | ± 10 ppm |
| 12.87176 | 32.7680 kHz Quartz SMD KX-327FT | KX-327F | 1.6 | 1.0 | 0.5 mm | 32.768 kHz | 7 pF | ± 20 ppm |
| 12.87177 | 32.7680 kHz Quartz SMD KX-327FT | KX-327F | 1.6 | 1.0 | 0.5 mm | 32.768 kHz | 12.5 pF | ± 20 ppm |
| 12.87178 | 32.7680 kHz Quartz SMD KX-327FT | KX-327F | 1.6 | 1.0 | 0.5 mm | 32.768 kHz | 4 pF | ± 20 ppm |
| 12.87180 | 32.7680 kHz Quartz SMD KX-327NHF | KX-327NH | 3.2 | 1.5 | 0.8 mm | 32.768 kHz | 9 pF | ± 20 ppm |
| 12.87181 | 32.7680 kHz Quartz SMD KX-327NHF | KX-327NH | 3.2 | 1.5 | 0.8 mm | 32.768 kHz | 12.5 pF | ± 20 ppm |
| 12.87182 | 32.7680 kHz Quartz SMD KX-327NHF | KX-327NH | 3.2 | 1.5 | 0.8 mm | 32.768 kHz | 7 pF | ± 20 ppm |
| 12.87183 | 32.7680 kHz Quartz SMD KX-327NHF | KX-327NH | 3.2 | 1.5 | 0.8 mm | 32.768 kHz | 12.5 pF | ± 10 ppm |
| 12.87186 | 32.7680 kHz Quartz SMD KX-327RF | KX-327R | 2.0 | 1.2 | 0.6 mm | 32.768 kHz | 12.5 pF | ± 20 ppm |
| 12.87187 | 32.7680 kHz Quartz SMD KX-327RT | KX-327R | 2.0 | 1.2 | 0.6 mm | 32.768 kHz | 6 pF | ± 20 ppm |
| 12.87188 | 32.7680 kHz Quartz SMD KX-327RF | KX-327R | 2.0 | 1.2 | 0.6 mm | 32.768 kHz | 9 pF | ± 20 ppm |
| 12.60000 | 16.0 MHz Quartz SMD KX-7T | KX-7 | 3.2 | 2.5 | 0.8 mm | 16.0 MHz | 12 pF | ± 20 ppm |
| 12.60001 | 27.120 MHz Quartz SMD KX-7 | KX-7 | 3.2 | 2.5 | 0.8 mm | 27.120 MHz | 10 pF | ± 30 ppm |
| 12.60003 | 26.0 MHz Quartz SMD KX-7 | KX-7 | 3.2 | 2.5 | 0.8 mm | 26.0 MHz | 12 pF | ± 30 ppm |
| 12.60004 | 13.8240 MHz Quartz SMD KX-7T | KX-7 | 3.2 | 2.5 | 0.8 mm | 13.8240 MHz | 12 pF | ± 30 ppm |
| 12.60005 | 26.0 MHz Quartz SMD KX-7T | KX-7 | 3.2 | 2.5 | 0.8 mm | 26.0 MHz | 10 pF | ± 10 ppm |
| 12.60006 | 16.0 MHz Quartz SMD KX-7T | KX-7 | 3.2 | 2.5 | 0.8 mm | 16.0 MHz | 10 pF | ± 20 ppm |
| 12.60007 | 14.74560 MHz Quartz SMD KX-7T | KX-7 | 3.2 | 2.5 | 0.8 mm | 14.74560 MHz | 16 pF | ± 30 ppm |
| 12.60009 | 25.0 MHz Quartz SMD KX-7T | KX-7 | 3.2 | 2.5 | 0.8 mm | 25.0 MHz | 20 pF | ± 20 ppm |
| 12.60010 | 16.3840 MHz Quartz SMD KX-7T | KX-7 | 3.2 | 2.5 | 0.8 mm | 16.3840 MHz | 18 pF | ± 20 ppm |
| 12.60011 | 40.0 MHz Quartz SMD KX-7 | KX-7 | 3.2 | 2.5 | 0.8 mm | 40.0 MHz | 8 pF | ± 10 ppm |
| 12.60012 | 16.0 MHz Quartz SMD KX-7E | KX-7 | 3.2 | 2.5 | 0.8 mm | 16.0 MHz | 16 pF | ± 30 ppm |
| 12.60013 | 50.0 MHz Quartz SMD KX-7T | KX-7 | 3.2 | 2.5 | 0.8 mm | 50.0 MHz | 18 pF | ± 30 ppm |
| 12.60014 | 13.0 MHz Quartz SMD KX-7T | KX-7 | 3.2 | 2.5 | 0.8 mm | 13.0 MHz | 10 pF | ± 30 ppm |
| 12.60015 | 12.0 MHz Quartz SMD KX-7 | KX-7 | 3.2 | 2.5 | 0.8 mm | 12.0 MHz | 16 pF | ± 30 ppm |
| 12.60016 | 12.0 MHz Quartz SMD KX-7F | KX-7 | 3.2 | 2.5 | 0.8 mm | 12.0 MHz | 12 pF | ± 30 ppm |
| 12.60017 | 32.0 MHz Quartz SMD KX-7T | KX-7 | 3.2 | 2.5 | 0.8 mm | 32.0 MHz | 8 pF | ± 10 ppm |
| 12.60018 | 24.0 MHz Quartz SMD KX-7T | KX-7 | 3.2 | 2.5 | 0.8 mm | 24.0 MHz | 18 pF | ± 13 ppm |
| 12.60019 | 26.0 MHz Quartz SMD KX-7 | KX-7 | 3.2 | 2.5 | 0.8 mm | 26.0 MHz | 18 pF | ± 30 ppm |
| 12.60020 | 12.0 MHz Quartz SMD KX-7F | KX-7 | 3.2 | 2.5 | 0.8 mm | 12.0 MHz | 8 pF | ± 10 ppm |
| 12.60021 | 16.0 MHz Quartz SMD KX-7 | KX-7 | 3.2 | 2.5 | 0.8 mm | 16.0 MHz | 7 pF | ± 10 ppm |
| 12.60022 | 8.0 MHz Quartz SMD KX-7T | KX-7 | 3.2 | 2.5 | 0.8 mm | 8.0 MHz | 8 pF | ± 20 ppm |
