AOCJYR-20.000MHZ-M5627LF,Abracon黑色面陶瓷晶振,OCXO恒温晶振
频率：20.000MHZ
尺寸：9.7*7.5*4.3mm
AOCJYR-20.000MHZ-M5627LF,Abracon黑色面陶瓷晶振,OCXO恒温晶振
AOCJYR-20.000MHZ-M5627LF是Abracon晶体振荡器专为卫星地面测控站打造的黑色面陶瓷封装OCXO恒温晶振,20MHz精准频点为测控信号的接收解调,指令发送提供超高精度时序.其OCXO恒温技术可将频率稳定度控制在±5ppb以内,彻底抵消环境温度波动带来的频偏,黑色面陶瓷封装兼具优异的隔热性与抗电磁干扰能力,能在测控站户外复杂环境中持续稳定运行,为航天测控数据的精准传输筑牢时基根基.
AOCJYR-20.000MHZ-M5627LF,Abracon黑色面陶瓷晶振,OCXO恒温晶振
|
原厂型号 Originalmodel： |
AOCJYR-20.000MHZ-M5627LF |
品牌brand： |
|
|
Manufacturer品牌 |
Abracon |
OperatingTemperature温度 |
-40+85℃ |
|
Series型号 |
AOCJYR |
Current-Supply(Max) |
- |
|
Type类型 |
OCXO |
PackageHeight高度 |
4.3mm |
|
Frequency频率 |
20M |
Termination 脚位 |
|
|
输出方式 Output： |
PackageType 封装类型 |
4-Smd |
|
|
Voltage-Supply电压 |
3.3V |
Packaging 包装 |
TapeandReel |
|
FrequencyStability频率稳定度 |
20PP |
安装方式 Installation： |
Surfacemount |
|
Size/Dimension尺寸 |
9.7*7.5*4.3mm |
最小包装数MPQ： |
1000 |
AOCJYR-20.000MHZ-M5627LF,Abracon黑色面陶瓷晶振,OCXO恒温晶振
AOCJYR-20.000MHZ-M5627LF,Abracon黑色面陶瓷晶振,OCXO恒温晶振
|
ABDFTCXO-10.000MHZ-E-2-CT |
Abracon |
ABDFTCXO |
TCXO |
14.2mm |
9.15mm |
3.1mm |
|
ABDFTCXO-10.000MHZ-E-2-T2 |
Abracon |
ABDFTCXO |
TCXO |
14.2mm |
9.15mm |
3.1mm |
|
ABDFTCXO-10.000MHZ-E-2-T5 |
Abracon |
ABDFTCXO |
TCXO |
14.2mm |
9.15mm |
3.1mm |
|
ABDFTCXO-10.000MHZ-L-2-CT |
Abracon |
ABDFTCXO |
TCXO |
14.2mm |
9.15mm |
3.1mm |
|
ABDFTCXO-10.000MHZ-L-2-T2 |
Abracon |
ABDFTCXO |
TCXO |
14.2mm |
9.15mm |
3.1mm |
|
ABDFTCXO-10.000MHZ-L-2-T5 |
Abracon |
ABDFTCXO |
TCXO |
14.2mm |
9.15mm |
3.1mm |
|
ABDFTCXO-12.800MHZ-E-2-CT |
Abracon |
ABDFTCXO |
TCXO |
14.2mm |
9.15mm |
3.1mm |
|
ABDFTCXO-12.800MHZ-E-2-T2 |
Abracon |
ABDFTCXO |
TCXO |
14.2mm |
9.15mm |
3.1mm |
|
ABDFTCXO-12.800MHZ-E-2-T5 |
Abracon |
ABDFTCXO |
TCXO |
14.2mm |
9.15mm |
3.1mm |
|
ABDFTCXO-12.800MHZ-L-2-CT |
Abracon |
ABDFTCXO |
TCXO |
14.2mm |
9.15mm |
3.1mm |
|
ABDFTCXO-12.800MHZ-L-2-T2 |
Abracon |
ABDFTCXO |
TCXO |
14.2mm |
9.15mm |
3.1mm |
|
ABDFTCXO-12.800MHZ-L-2-T5 |
Abracon |
ABDFTCXO |
TCXO |
14.2mm |
9.15mm |
3.1mm |
|
ABDFTCXO-16.000MHZ-E-2-CT |
Abracon |
ABDFTCXO |
TCXO |
14.2mm |
9.15mm |
3.1mm |
|
ABDFTCXO-16.000MHZ-E-2-T2 |
Abracon |
ABDFTCXO |
TCXO |
14.2mm |
9.15mm |
3.1mm |
|
ABDFTCXO-16.000MHZ-E-2-T5 |
Abracon |
ABDFTCXO |
TCXO |
14.2mm |
9.15mm |
3.1mm |
|
ABDFTCXO-16.000MHZ-L-2-CT |
Abracon |
ABDFTCXO |
TCXO |
14.2mm |
9.15mm |
3.1mm |
|
ABDFTCXO-16.000MHZ-L-2-T2 |
Abracon |
ABDFTCXO |
TCXO |
14.2mm |
9.15mm |
3.1mm |
|
ABDFTCXO-16.000MHZ-L-2-T5 |
Abracon |
ABDFTCXO |
TCXO |
14.2mm |
9.15mm |
3.1mm |
|
ABDFTCXO-16.384MHZ-E-2-CT |
Abracon |
ABDFTCXO |
TCXO |
14.2mm |
9.15mm |
3.1mm |
|
ABDFTCXO-16.384MHZ-E-2-T2 |
Abracon |
ABDFTCXO |
TCXO |
14.2mm |
9.15mm |
3.1mm |
|
ABDFTCXO-16.384MHZ-E-2-T5 |
Abracon |
ABDFTCXO |
TCXO |
14.2mm |
9.15mm |
3.1mm |
|
ABDFTCXO-16.384MHZ-L-2-CT |
Abracon |
ABDFTCXO |
TCXO |
14.2mm |
9.15mm |
3.1mm |
|
ABDFTCXO-16.384MHZ-L-2-T2 |
Abracon |
ABDFTCXO |
TCXO |
14.2mm |
9.15mm |
3.1mm |
|
ABDFTCXO-16.384MHZ-L-2-T5 |
Abracon |
ABDFTCXO |
TCXO |
14.2mm |
9.15mm |
3.1mm |
|
ABDFTCXO-19.200MHZ-E-2-CT |
Abracon |
ABDFTCXO |
TCXO |
14.2mm |
9.15mm |
3.1mm |
|
ABDFTCXO-19.200MHZ-E-2-T2 |
Abracon |
ABDFTCXO |
TCXO |
14.2mm |
9.15mm |
3.1mm |
|
ABDFTCXO-19.200MHZ-E-2-T5 |
Abracon |
ABDFTCXO |
TCXO |
14.2mm |
9.15mm |
3.1mm |
|
ABDFTCXO-19.200MHZ-L-2-CT |
Abracon |
ABDFTCXO |
TCXO |
14.2mm |
9.15mm |
3.1mm |
|
ABDFTCXO-19.200MHZ-L-2-T2 |
Abracon |
ABDFTCXO |
TCXO |
14.2mm |
9.15mm |
3.1mm |
|
ABDFTCXO-19.200MHZ-L-2-T5 |
Abracon |
ABDFTCXO |
TCXO |
14.2mm |
9.15mm |
3.1mm |
|
ABDFTCXO-19.440MHZ-E-2-CT |
Abracon |
ABDFTCXO |
TCXO |
14.2mm |
9.15mm |
3.1mm |
|
ABDFTCXO-19.440MHZ-E-2-T2 |
Abracon |
ABDFTCXO |
TCXO |
14.2mm |
9.15mm |
3.1mm |
|
ABDFTCXO-19.440MHZ-E-2-T5 |
Abracon |
ABDFTCXO |
TCXO |
14.2mm |
9.15mm |
3.1mm |
|
ABDFTCXO-19.440MHZ-L-2-CT |
Abracon |
ABDFTCXO |
TCXO |
14.2mm |
9.15mm |
3.1mm |
|
ABDFTCXO-19.440MHZ-L-2-T2 |
Abracon |
ABDFTCXO |
TCXO |
14.2mm |
9.15mm |
3.1mm |
|
ABDFTCXO-19.440MHZ-L-2-T5 |
Abracon |
ABDFTCXO |
TCXO |
14.2mm |
9.15mm |
3.1mm |
|
ABDFTCXO-20.000MHZ-E-2-CT |
Abracon |
ABDFTCXO |
TCXO |
14.2mm |
9.15mm |
3.1mm |
|
ABDFTCXO-20.000MHZ-E-2-T2 |
Abracon |
ABDFTCXO |
TCXO |
14.2mm |
9.15mm |
3.1mm |
|
ABDFTCXO-20.000MHZ-E-2-T5 |
Abracon |
ABDFTCXO |
TCXO |
14.2mm |
9.15mm |
3.1mm |
|
ABDFTCXO-20.000MHZ-L-2-CT |
Abracon |
ABDFTCXO |
TCXO |
14.2mm |
9.15mm |
3.1mm |
|
ABDFTCXO-20.000MHZ-L-2-T2 |
Abracon |
ABDFTCXO |
TCXO |
14.2mm |
9.15mm |
3.1mm |
|
ABDFTCXO-20.000MHZ-L-2-T5 |
Abracon |
ABDFTCXO |
TCXO |
14.2mm |
9.15mm |
3.1mm |
|
ABDFTCXO-24.576MHZ-E-2-CT |
Abracon |
ABDFTCXO |
TCXO |
14.2mm |
9.15mm |
3.1mm |
|
ABDFTCXO-24.576MHZ-E-2-T2 |
Abracon |
ABDFTCXO |
TCXO |
14.2mm |
9.15mm |
3.1mm |
|
ABDFTCXO-24.576MHZ-E-2-T5 |
Abracon |
ABDFTCXO |
TCXO |
14.2mm |
9.15mm |
3.1mm |
|
ABDFTCXO-24.576MHZ-L-2-CT |
Abracon |
ABDFTCXO |
TCXO |
14.2mm |
9.15mm |
3.1mm |
|
ABDFTCXO-24.576MHZ-L-2-T2 |
Abracon |
ABDFTCXO |
TCXO |
14.2mm |
9.15mm |
3.1mm |
|
ABDFTCXO-24.576MHZ-L-2-T5 |
Abracon |
ABDFTCXO |
TCXO |
14.2mm |
9.15mm |
3.1mm |
|
ABDFTCXO-25.000MHZ-E-2-CT |
Abracon |
ABDFTCXO |
TCXO |
14.2mm |
9.15mm |
3.1mm |
|
ABDFTCXO-25.000MHZ-E-2-T2 |
Abracon |
ABDFTCXO |
TCXO |
14.2mm |
9.15mm |
3.1mm |
|
ABDFTCXO-25.000MHZ-E-2-T5 |
Abracon |
ABDFTCXO |
TCXO |
14.2mm |
9.15mm |
3.1mm |
|
ABDFTCXO-25.000MHZ-L-2-CT |
Abracon |
ABDFTCXO |
TCXO |
14.2mm |
9.15mm |
3.1mm |
|
ABDFTCXO-25.000MHZ-L-2-T2 |
Abracon |
ABDFTCXO |
TCXO |
14.2mm |
9.15mm |
3.1mm |
|
ABDFTCXO-25.000MHZ-L-2-T5 |
Abracon |
ABDFTCXO |
TCXO |
14.2mm |
9.15mm |
3.1mm |
|
ABDFTCXO-26.000MHZ-E-2-CT |
Abracon |
ABDFTCXO |
TCXO |
14.2mm |
9.15mm |
3.1mm |
|
ABDFTCXO-26.000MHZ-E-2-T2 |
Abracon |
ABDFTCXO |
TCXO |
14.2mm |
9.15mm |
3.1mm |
|
ABDFTCXO-26.000MHZ-E-2-T5 |
Abracon |
ABDFTCXO |
TCXO |
14.2mm |
9.15mm |
3.1mm |
|
ABDFTCXO-26.000MHZ-L-2-CT |
Abracon |
ABDFTCXO |
TCXO |
14.2mm |
9.15mm |
3.1mm |
|
ABDFTCXO-26.000MHZ-L-2-T2 |
Abracon |
ABDFTCXO |
TCXO |
14.2mm |
9.15mm |
3.1mm |
|
ABDFTCXO-26.000MHZ-L-2-T5 |
Abracon |
ABDFTCXO |
TCXO |
14.2mm |
9.15mm |
3.1mm |
