进口大真空3225晶振,1XVD030240VA压控晶振,6G物联网终端DSV321SV晶振

进口大真空3225晶振,1XVD030240VA压控晶振,6G物联网终端DSV321SV晶振，日本KDS晶振公司，小尺寸晶振，3225晶振，6G物联网终端晶振，6G通讯模块晶振，6G发射器晶振，压控晶振，有源晶振，石英晶振，KDS贴片晶振，3225尺寸，厚度1.1mm，小型SMD-VCXO，在小型的情况下确保足够的变量，，频率变化的模拟VCXO，低耗电流，DVD，数字电视，STB, ADSL，基础传输用。

yijin-2

进口大真空3225晶振,1XVD030240VA压控晶振,6G物联网终端DSV321SV晶振

项目	型号	記号	DSV321SV		DSV321SR
频率范围		fo	13.5?54MHz	6.75?90MHz	13.5?54MHz
电源电压		VCC	+2.8V±0.28V	+3.3V±0.33V	+1.8V±0. 18V
频率控制电压		Vcont	＋1 .4±1.4V	＋1 .65±1.65V	＋0 .9±0.9V
储存温度范围		T_stg	−40?+85℃
工作温度范围		T_use	−10?＋70℃ /−30?＋85℃
温度范围内的频率偏差度		f_tol	±40×10−6
频率容差		f_cont	±125×10−6min./±100×10−6min. [Positive Slope]		±100×10−6min. [Positive Slope]
消耗电流		ICC	3mA max. (13 .5≦fo≦40MHz) 5mA max. (40＜fo≦54MHz) [No Load]	5mA max. (6 .75≦fo≦40MHz) 8mA max. (40＜fo≦54MHz) 12mA max. (54＜fo≦90MHz) [No Load]	2mA max. (13 .5≦fo≦36MHz) 3mA max. (36＜fo≦54MHz) [No Load]
输出负荷		L_CMOS	15pF
波形识别器		SYM	40?60% [50％ VCCLevel]
零电平电压		VOL	VCC ×0. 1 max.
一级电压		VOH	VCC ×0.9 min.
上升时间和下降时间		tr, tf	10ns max. (13.5 ≦fo≦40MHz) 6ns max. (40＜fo≦54MHz) [10?90％ VCC Level]	10ns max. (6 .75≦fo≦40MHz) 6ns max. (40＜fo≦54MHz) 4ns max. (54＜fo≦90MHz) [10?90％ VCCLevel]	10ns max. (13 .5≦fo≦40MHz) 6ns max. (40＜fo≦54MHz) [10?90％ VCC Level]
结束		tRMS	2.4ps typ. (σ)		3.5ps typ. (σ)
		tp-p	22ps typ. (Peak to peak)		32ps typ. (Peak to peak)
总抖动		tTL	33ps typ. [tDJ + n＊tRJn=14. 1(BER=1＊10- 12)(2)]		49ps typ. [tDJ + n＊tRJ n=14. 1BER=1＊10- 12)(2)]
相位抖动		tpj	1ps max. (10≦fo<40MHz,fo offset：12kHz?5MHz、 fo≧40MHz,fo offset：12kHz?20MHz))		1.5ps max. (fo<40MHz,fo offset：12kHz?5MHz、 fo≧40MHz,fo offset：12kHz?20MHz)
包装单位		−	2000pcs./reel(φ180)

进口大真空3225晶振,1XVD030240VA压控晶振,6G物联网终端DSV321SV晶振

品牌	原厂代码	型号	尺寸	频率	负载/电压	精度
KDS晶振	1XSE098304AR2	DSO321SR	3225	98.304MHZ	3.3V	50ppm
KDS晶振	ZC08759	DSO211AH	2016	25.000MHZ	3.3V	50ppm
KDS晶振	1XSE009600AV	DSO321SV	3225	9.6MHZ	3.3V	100ppm
KDS晶振	1XSE012000AR58	DSO321SR	3225	12.000MHZ	3.3V	50ppm
KDS晶振	1XSA050000AVW	DSO751SV	7050	50.000MHZ	3.3V	100ppm
KDS晶振	1XSR025000AR25	DSO751SR	7050	25.000MHZ	3.3V	50ppm
KDS晶振	1D21407AQ3	DSF753SAF	7050	21.400MHZ
KDS晶振	1XTW16368FEA	DSB321SCL	3225	16.368MHZ	2.8V	2.5ppm
KDS晶振	1XSF033333ARA	DSO221SR	2520	33.3333MHZ
KDS晶振	7FE02496A00H0000008	DSO221SX	2520	24.96MHZ
KDS晶振	1XSE038702AR	DSO321SR	3225	38.7024MHZ
KDS晶振	1XST156250AKM	DSO323SK	3225	156.25MHZ		50PPM
KDS晶振	1XSE025000AR5	DSO321SR	3225	25.000MHZ
KDS晶振	1XSE050000ART	DSO321SR	3225	50MHZ
KDS晶振	1XSE024000AW1	DSO321SW	3225	24.000MHZ
KDS晶振	1XSE033333ARD	DSO321SR	3225	33.3333MHZ
KDS晶振	1D73375GR1	DSF633SDF		73.35MHZ
KDS晶振	1XSE013000AR7	DSO321SR	3225	13.000MHZ	1.8V	50PPM
KDS晶振	1XSE025000AR17	DSO321SR	3225	25.000MHZ	3.3V	50PPM
KDS晶振	1XSF022579EH1	DSO221SHF	2520	22.5792MHZ	1.8V	50PPM
KDS晶振	1XSE038400AR	DSO321SR	3225	38.4MHZ	1.8V	12PPM
KDS晶振	1XSE024000AR83	DSO321SR	3225	24.000MHZ	1.8V	20PPM
KDS晶振	1XSF027000EH6	DSO221SHF	2520	27.000MHZ	3.3V	30PPM
KDS晶振	1XSF033333ARD	DSO221SHF	2520	33.333MHZ	3.3V	50PPM
KDS晶振	1XSE027000AR128	DSO321SR	3225	27.000MHZ	1.8V	25PPM
KDS晶振	1XSF024000AR29	DSO221SHF	2520	24.000MHZ	0	0
KDS晶振	1XTW19200MCA	DSB321SDN	3225	19.2MHZ	3V	1.5PPM
KDS晶振	1XSE045000AR8	DSO321SR	3225	45MHZ	3.3V	0
KDS晶振	1XSE050000AV6	DSO321SR	3225	50.000MHZ	3.3V	50PPM
KDS晶振	1XSE054000AR5	DSO321SR	3225	54MHZ	3.3V	30PPM
KDS晶振	1XSE064000AB	DSO321SR	3225	64MHZ	5V	100PPM
KDS晶振	1XSE150000AR1	DSO321SR	3225	150.000MHZ	3.3V	50PPM
KDS晶振	1XSR004000AB	DSO751SB	7050	4MHZ	3.3V	40PPM
KDS晶振	1XSD048000AV2	DSO531SV	5032	48.000MHZ	3.3V	0
KDS晶振	1XTW26000MAA	DSB321SDN	3225	26.000MHZ
KDS晶振	1XTW26000CGA	DSB321SDA	3225	26.000MHZ
KDS晶振	1XTW16368MAA	DSB321SDN	3225	16.368MHZ
KDS晶振	1XTW16367CFB	DSB321SDA	3225	16.367667MHZ
KDS晶振	1XTW16367CF	DSB321SDA	3225	16.367667MHZ
KDS晶振	1XSF026000AH6	DSO221SH	2520	26.000MHZ	1.8V	20PPM
KDS晶振	1XSF006140AR	DSO221SR	2520	6.140MHZ
KDS晶振	1XTW10000CAB	DSB321SDA	3225	10.000MHZ
KDS晶振	1XSE010000ARV	DSO321SR	3225	10.000MHZ
KDS晶振	1XSE012000ARH	DSO321SR	3225	12.000MHZ
KDS晶振	1XTW12288FAB	DSB321SCL	3225	12.288MHZ
KDS晶振	1XSF012288EH1	DSO221SHF	2520	12.288MHZ
KDS晶振	1XTW14745FBA	DSB321SCL	3225	14.7456MHZ
KDS晶振	1XTW16367ADA	DSB321SCA	3225	16.367667MHZ
KDS晶振	1XTW16367MAA	DSB321SDN	3225	16.367667MHZ
KDS晶振	1XTW16369MAA	DSB321SDN	3225	16.369MHZ
KDS晶振	1XSE019200AR7	DSO321SR	3225	19.200MHZ
KDS晶振	1XTW20000AAA	DSB321SCA	3225	20.000MHZ
KDS晶振	1XTW20000CCA	DSB321SDA	3225	20.000MHZ
KDS晶振	1XSE024576ARH	DSO321SR	3225	24.576MHZ
KDS晶振	1XTR25000VAA	DSB535SD	5032	25.000MHZ
KDS晶振	1XSE025000ARW	DSO321SR	3225	25.000MHZ
KDS晶振	1XTW29491FAA	DSB321SDA	3225	29.4912MHZ
KDS晶振	1XTW30000FCA	DSB321SCL	3225	30.000MHZ
KDS晶振	1XTW40000FBA	DSB321SCL	3225	40.000MHZ
KDS晶振	1D45015GQ48	DSF751SBF	5070	45.000MHZ
KDS晶振	1XTW52000FAA	DSB321SCL	3225	52.000MHZ
