现代化智能建筑物与高性能GEYER晶振

当系统和组件相互联网，从而可以数字化控制过程时，建筑物就是智能的。

现代智能建筑大多是自动化的、节能的、供应分散产生的能源，并且在电力和热量使用方面是可控的。作为现代化和翻新项目的一部分，现有建筑也可以成为智能建筑。

GEYER晶振给予能源效率适当的打击，我们的产品可以在每个智能建筑的各种设计中找到，并确保安装在其中的控制和测量仪器的功能。智能建筑提供分散产生的能源，并且可以根据其消耗进行精确控制。通过这种方式，我们GEYER电子正在用最小的组件为大局做出贡献:通过更高的能源效率实现能源周转。

无论是电表还是电梯-我们为智能建筑提供精确的频率产品

可以向智能手机报告食物缺失的会说话的冰箱，或者通过可控制的百叶窗自动日出，这只是智能建筑大领域的两个小例子。

A building is smart when systems and components are networked with each other so that processes can be controlled digitally.

Modern, intelligent buildings are mostly automated, energy-efficient, supply decentrally generated energy and are controllable in terms of electricity and heat use. Existing buildings can also become smart buildings as part of modernization and refurbishment projects.

We give energy efficiency the right beat

Our products can be found in a wide variety of designs in every smart building and ensure the function of the control and measurement instruments installed in them. Smart buildings supply decentrally generated energy and can be precisely controlled in terms of their consumption. In this way, we at GEYER Electronic are making our contribution to the big picture with the smallest components: the energy turnaround through greater energy efficiency.

Whether electricity meter or elevator – we supply precise frequency products for smart buildings技术支持

The talking refrigerator that reports missing food to the smartphone or the automatic sunrise through controllable blinds are just two small examples of the large field of smart building.

编码	描述	型号	尺寸	频率	负载	频率容差
12.87000	32.7680 kHz Quartz SMD KX-327VT	KX-327V	1.25 \| 1.05 \| 0.5 mm	32.768 kHz	12.5 pF	± 20 ppm
12.87001	32.7680 kHz Quartz SMD KX-327VT	KX-327V	1.25 \| 1.05 \| 0.5 mm	32.768 kHz	9 pF	± 20 ppm
12.87002	32.7680 kHz Quartz SMD KX-327VT	KX-327V	1.25 \| 1.05 \| 0.5 mm	32.768 kHz	7 pF	± 20 ppm
12.87034	32.7680 kHz Quartz SMD KX-327RT	KX-327R	2.0 \| 1.2 \| 0.6 mm	32.768 kHz	4 pF	± 20 ppm
12.87080	32.7680 kHz Quartz SMD KX-327NHT	KX-327NH	3.2 \| 1.5 \| 0.8 mm	32.768 kHz	12.5 pF	± 10 ppm
12.87081	32.7680 kHz Quartz SMD KX-327NHT	KX-327NH	3.2 \| 1.5 \| 0.8 mm	32.768 kHz	6 pF	± 20 ppm
12.87083	32.7680 kHz Quartz SMD KX-327NHT	KX-327NH	3.2 \| 1.5 \| 0.8 mm	32.768 kHz	6 pF	± 20 ppm
12.87086	32.7680 kHz Quartz SMD KX-327NHT	KX-327NH	3.2 \| 1.5 \| 0.8 mm	32.768 kHz	6 pF	± 10 ppm
12.87090	32.7680 kHz Quartz SMD KX-327NHT	KX-327NH	3.2 \| 1.5 \| 0.8 mm	32.768 kHz	7 pF	± 10 ppm
12.87095	32.7680 kHz Quartz SMD KX-327NHT	KX-327NH	3.2 \| 1.5 \| 0.8 mm	32.768 kHz	9 pF	± 10 ppm
12.87105	32,7680 kHz Quartz SMD KX-327ST	KX-327S	8.2 \| 3.8 \| 2.5 mm	32.768 kHz	6 pF	± 10 ppm
12.87107	32.7680 kHz Quartz SMD KX-327S	KX-327S	8.2 \| 3.8 \| 2.5 mm	32.768 kHz	12.5 pF	± 20 ppm
12.87109	32.7680 kHz Quartz SMD KX-327ST	KX-327S	8.2 \| 3.8 \| 2.5 mm	32.768 kHz	12 pF	± 15 ppm
12.87110	32.7680 kHz Quartz SMD KX-327S	KX-327S	8.2 \| 3.8 \| 2.5 mm	32.768 kHz	12.5 pF	± 30 ppm
12.87111	32.7680 kHz Quartz SMD KX-327ST	KX-327S	8.2 \| 3.8 \| 2.5 mm	32.768 kHz	12.5 pF	± 30 ppm
12.87112	32.7680 kHz Quartz SMD KX-327S	KX-327S	8.2 \| 3.8 \| 2.5 mm	32.768 kHz	12.5 pF	± 20 ppm
12.87113	32.7680 kHz Quartz SMD KX-327S	KX-327S	8.2 \| 3.8 \| 2.5 mm	32.768 kHz	12.5 pF	± 5.0 ppm
12.87114	32.7680 kHz Quartz SMD KX-327ST	KX-327S	8.2 \| 3.8 \| 2.5 mm	32.768 kHz	12.5 pF	± 20 ppm
12.87115	32.7680 kHz Quartz SMD KX-327ST	KX-327S	8.2 \| 3.8 \| 2.5 mm	32.768 kHz	12.5 pF	± 10 ppm
12.87116	32.7680 kHz Quartz SMD KX-327S	KX-327S	8.2 \| 3.8 \| 2.5 mm	32.768 kHz	12.5 pF	± 10 ppm
12.87118	32.7680 kHz Quartz SMD KX-327S	KX-327S	8.2 \| 3.8 \| 2.5 mm	32.768 kHz	6 pF	± 20 ppm
12.87119	32.7680 kHz Quartz SMD KX-327ST	KX-327S	8.2 \| 3.8 \| 2.5 mm	32.768 kHz	6 pF	± 20 ppm
12.87120	32.7680 kHz Quartz SMD KX-327XS	KX-327XS	4.95 \| 1.82 \| 0.96 mm	32.768 kHz	12.5 pF	± 30 ppm
12.87121	32.7680 kHz Quartz SMD KX-327XST	KX-327XS	4.95 \| 1.82 \| 0.96 mm	32.768 kHz	12.5 pF	± 30 ppm
12.87123	32.7680 kHz Quartz SMD KX-327XS	KX-327XS	4.95 \| 1.82 \| 0.96 mm	32.768 kHz	6 pF	± 30 ppm
12.87126	32.7680 kHz Quartz SMD KX-327XS	KX-327XS	4.95 \| 1.82 \| 0.96 mm	32.768 kHz	12.5 pF	± 20 ppm
12.87127	32.7680 kHz Quartz SMD KX-327XST	KX-327XS	4.95 \| 1.82 \| 0.96 mm	32.768 kHz	6 pF	± 30 ppm
12.87128	32.7680 kHz Quartz SMD KX-327XST	KX-327XS	4.95 \| 1.82 \| 0.96 mm	32.768 kHz	6 pF	± 20 ppm
12.87129	32.7680 kHz Quartz SMD KX-327XST	KX-327XS	4.95 \| 1.82 \| 0.96 mm	32.768 kHz	12.5 pF	± 20 ppm
12.87130	32.7680 kHz Quartz SMD KX-327L	KX-327L	7.0 \| 1.5 \| 1.4 mm	32.768 kHz	12.5 pF	± 20 ppm
12.87131	32.7680 kHz Quartz SMD KX-327LT	KX-327L	7.0 \| 1.5 \| 1.4 mm	32.768 kHz	12.5 pF	± 20 ppm
12.87132	32.7680 kHz Quartz SMD KX-327L	KX-327L	7.0 \| 1.5 \| 1.4 mm	32.768 kHz	7 pF	± 20 ppm
12.87133	32.7680 kHz Quartz SMD KX-327L	KX-327L	7.0 \| 1.5 \| 1.4 mm	32.768 kHz	12.5 pF	± 10 ppm
12.87134	32.7680 kHz Quartz SMD KX-327L	KX-327L	7.0 \| 1.5 \| 1.4 mm	32.768 kHz	7 pF	± 10 ppm
12.87135	32.7680 kHz Quartz SMD KX-327LT	KX-327L	7.0 \| 1.5 \| 1.4 mm	32.768 kHz	7 pF	± 20 ppm
12.87136	32.7680 kHz Quartz SMD KX-327LT	KX-327L	7.0 \| 1.5 \| 1.4 mm	32.768 kHz	12.5 pF	± 10 ppm
12.87137	32.7680 kHz Quartz SMD KX-327LT	KX-327L	7.0 \| 1.5 \| 1.4 mm	32.768 kHz	9 pF	± 20 ppm
12.87138	32.7680 kHz Quartz SMD KX-327LT	KX-327L	7.0 \| 1.5 \| 1.4 mm	32.768 kHz	12.5 pF	± 5.0 ppm
12.87139	32.7680 kHz Quartz SMD KX-327LT	KX-327L	7.0 \| 1.5 \| 1.4 mm	32.768 kHz	7 pF	± 10 ppm
12.87143	32.7680 kHz Quartz SMD KX-327NHT	KX-327NH	3.2 \| 1.5 \| 0.8 mm	32.768 kHz	9 pF	± 20 ppm
12.87144	32.7680 kHz Quartz SMD KX-327NHT	KX-327NH	3.2 \| 1.5 \| 0.8 mm	32.768 kHz	7 pF	± 5.0 ppm
12.87145	32.7680 kHz Quartz SMD KX-327NHT	KX-327NH	3.2 \| 1.5 \| 0.8 mm	32.768 kHz	12.5 pF	± 20 ppm
12.87146	32.7680 kHz Quartz SMD KX-327NHT	KX-327NH	3.2 \| 1.5 \| 0.8 mm	32.768 kHz	9 pF	± 10 ppm
12.87147	32.7680 kHz Quartz SMD KX-327NHT	KX-327NH	3.2 \| 1.5 \| 0.8 mm	32.768 kHz	7 pF	± 10 ppm
12.87148	32.7680 kHz Quartz SMD KX-327NHT	KX-327NH	3.2 \| 1.5 \| 0.8 mm	32.768 kHz	7 pF	± 20 ppm
12.87149	32.7680 kHz Quartz SMD KX-327NHT	KX-327NH	3.2 \| 1.5 \| 0.8 mm	32.768 kHz	9 pF	± 20 ppm
12.87150	32.7680 kHz Quartz SMD KX-327NHT	KX-327NH	3.2 \| 1.5 \| 0.8 mm	32.768 kHz	12.5 pF	± 20 ppm
12.87151	32.7680 kHz Quartz SMD KX-327NHT	KX-327NH	3.2 \| 1.5 \| 0.8 mm	32.768 kHz	9 pF	± 30 ppm
12.87152	32.7680 kHz Quartz SMD KX-327NHH	KX-327NH	3.2 \| 1.5 \| 0.8 mm	32.768 kHz	12.5 pF	± 20 ppm
12.87153	32.7680 kHz Quartz SMD KX-327NHT	KX-327NH	3.2 \| 1.5 \| 0.8 mm	32.768 kHz	7 pF	± 20 ppm
12.87155	32.7680 kHz Quartz SMD KX-327NHE	KX-327NH	3.2 \| 1.5 \| 0.8 mm	32.768 kHz	12.5 pF	± 30 ppm
12.87157	32.7680 kHz Quartz SMD KX-327NHT	KX-327NH	3.2 \| 1.5 \| 0.8 mm	32.768 kHz	12.5 pF	± 5.0 ppm
12.87158	32.7680 kHz Quartz SMD KX-327NHT	KX-327NH	3.2 \| 1.5 \| 0.8 mm	32.768 kHz	12.5 pF	± 10 ppm
12.87159	32.7680 kHz Quartz SMD KX-327NHT	KX-327NH	3.2 \| 1.5 \| 0.8 mm	32.768 kHz	12.5 pF	± 20 ppm
12.87160	32.7680 kHz Quartz SMD KX-327RT	KX-327R	2.0 \| 1.2 \| 0.6 mm	32.768 kHz	12.5 pF	± 20 ppm
12.87161	32.7680 kHz Quartz SMD KX-327RT	KX-327R	2.0 \| 1.2 \| 0.6 mm	32.768 kHz	12.5 pF	± 5.0 ppm
12.87163	32.7680 kHz Quartz SMD KX-327RT	KX-327R	2.0 \| 1.2 \| 0.6 mm	32.768 kHz	7 pF	± 20 ppm
12.87164	32.7680 kHz Quartz SMD KX-327RT	KX-327R	2.0 \| 1.2 \| 0.6 mm	32.768 kHz	9 pF	± 30 ppm
12.87165	32.7680 kHz Quartz SMD KX-327RT	KX-327R	2.0 \| 1.2 \| 0.6 mm	32.768 kHz	9 pF	± 20 ppm
12.87166	32.7680 kHz Quartz SMD KX-327RF	KX-327R	2.0 \| 1.2 \| 0.6 mm	32.768 kHz	12.5 pF	± 20 ppm
12.87167	32.7680 kHz Quartz SMD KX-327RT	KX-327R	2.0 \| 1.2 \| 0.6 mm	32.768 kHz	12.5 pF	± 10 ppm
12.87168	32.7680 kHz Quartz SMD KX-327RF	KX-327R	2.0 \| 1.2 \| 0.6 mm	32.768 kHz	9 pF	± 20 ppm
12.87169	32.7680 kHz Quartz SMD KX-327RT	KX-327R	2.0 \| 1.2 \| 0.6 mm	32.768 kHz	9 pF	± 10 ppm
12.87170	32.7680 kHz Quartz SMD KX-327FT	KX-327F	1.6 \| 1.0 \| 0.5 mm	32.768 kHz	12.5 pF	± 20 ppm
12.87171	32.7680 kHz Quartz SMD KX-327FT	KX-327F	1.6 \| 1.0 \| 0.5 mm	32.768 kHz	12.5 pF	± 10 ppm
12.87172	32.7680 kHz Quartz SMD KX-327FT	KX-327F	1.6 \| 1.0 \| 0.5 mm	32.768 kHz	9 pF	± 20 ppm
12.87173	32.7680 kHz Quartz SMD KX-327FT	KX-327F	1.6 \| 1.0 \| 0.5 mm	32.768 kHz	9 pF	± 10 ppm
12.87174	32.7680 kHz Quartz SMD KX-327FT	KX-327F	1.6 \| 1.0 \| 0.5 mm	32.768 kHz	7 pF	± 20 ppm
12.87175	32.7680 kHz Quartz SMD KX-327FT	KX-327F	1.6 \| 1.0 \| 0.5 mm	32.768 kHz	7 pF	± 10 ppm
12.87176	32.7680 kHz Quartz SMD KX-327FT	KX-327F	1.6 \| 1.0 \| 0.5 mm	32.768 kHz	7 pF	± 20 ppm
12.87177	32.7680 kHz Quartz SMD KX-327FT	KX-327F	1.6 \| 1.0 \| 0.5 mm	32.768 kHz	12.5 pF	± 20 ppm
12.87178	32.7680 kHz Quartz SMD KX-327FT	KX-327F	1.6 \| 1.0 \| 0.5 mm	32.768 kHz	4 pF	± 20 ppm
12.87180	32.7680 kHz Quartz SMD KX-327NHF	KX-327NH	3.2 \| 1.5 \| 0.8 mm	32.768 kHz	9 pF	± 20 ppm
12.87181	32.7680 kHz Quartz SMD KX-327NHF	KX-327NH	3.2 \| 1.5 \| 0.8 mm	32.768 kHz	12.5 pF	± 20 ppm
12.87182	32.7680 kHz Quartz SMD KX-327NHF	KX-327NH	3.2 \| 1.5 \| 0.8 mm	32.768 kHz	7 pF	± 20 ppm
12.87183	32.7680 kHz Quartz SMD KX-327NHF	KX-327NH	3.2 \| 1.5 \| 0.8 mm	32.768 kHz	12.5 pF	± 10 ppm
12.87186	32.7680 kHz Quartz SMD KX-327RF	KX-327R	2.0 \| 1.2 \| 0.6 mm	32.768 kHz	12.5 pF	± 20 ppm
12.87187	32.7680 kHz Quartz SMD KX-327RT	KX-327R	2.0 \| 1.2 \| 0.6 mm	32.768 kHz	6 pF	± 20 ppm
12.87188	32.7680 kHz Quartz SMD KX-327RF	KX-327R	2.0 \| 1.2 \| 0.6 mm	32.768 kHz	9 pF	± 20 ppm
12.60000	16.0 MHz Quartz SMD KX-7T	KX-7	3.2 \| 2.5 \| 0.8 mm	16.0 MHz	12 pF	± 20 ppm
12.60001	27.120 MHz Quartz SMD KX-7	KX-7	3.2 \| 2.5 \| 0.8 mm	27.120 MHz	10 pF	± 30 ppm
12.60003	26.0 MHz Quartz SMD KX-7	KX-7	3.2 \| 2.5 \| 0.8 mm	26.0 MHz	12 pF	± 30 ppm
12.60004	13.8240 MHz Quartz SMD KX-7T	KX-7	3.2 \| 2.5 \| 0.8 mm	13.8240 MHz	12 pF	± 30 ppm
12.60005	26.0 MHz Quartz SMD KX-7T	KX-7	3.2 \| 2.5 \| 0.8 mm	26.0 MHz	10 pF	± 10 ppm
12.60006	16.0 MHz Quartz SMD KX-7T	KX-7	3.2 \| 2.5 \| 0.8 mm	16.0 MHz	10 pF	± 20 ppm
12.60007	14.74560 MHz Quartz SMD KX-7T	KX-7	3.2 \| 2.5 \| 0.8 mm	14.74560 MHz	16 pF	± 30 ppm
12.60009	25.0 MHz Quartz SMD KX-7T	KX-7	3.2 \| 2.5 \| 0.8 mm	25.0 MHz	20 pF	± 20 ppm
12.60010	16.3840 MHz Quartz SMD KX-7T	KX-7	3.2 \| 2.5 \| 0.8 mm	16.3840 MHz	18 pF	± 20 ppm
12.60011	40.0 MHz Quartz SMD KX-7	KX-7	3.2 \| 2.5 \| 0.8 mm	40.0 MHz	8 pF	± 10 ppm
12.60012	16.0 MHz Quartz SMD KX-7E	KX-7	3.2 \| 2.5 \| 0.8 mm	16.0 MHz	16 pF	± 30 ppm
12.60013	50.0 MHz Quartz SMD KX-7T	KX-7	3.2 \| 2.5 \| 0.8 mm	50.0 MHz	18 pF	± 30 ppm
12.60014	13.0 MHz Quartz SMD KX-7T	KX-7	3.2 \| 2.5 \| 0.8 mm	13.0 MHz	10 pF	± 30 ppm
12.60015	12.0 MHz Quartz SMD KX-7	KX-7	3.2 \| 2.5 \| 0.8 mm	12.0 MHz	16 pF	± 30 ppm
12.60016	12.0 MHz Quartz SMD KX-7F	KX-7	3.2 \| 2.5 \| 0.8 mm	12.0 MHz	12 pF	± 30 ppm
12.60017	32.0 MHz Quartz SMD KX-7T	KX-7	3.2 \| 2.5 \| 0.8 mm	32.0 MHz	8 pF	± 10 ppm
12.60018	24.0 MHz Quartz SMD KX-7T	KX-7	3.2 \| 2.5 \| 0.8 mm	24.0 MHz	18 pF	± 13 ppm
12.60019	26.0 MHz Quartz SMD KX-7	KX-7	3.2 \| 2.5 \| 0.8 mm	26.0 MHz	18 pF	± 30 ppm
12.60020	12.0 MHz Quartz SMD KX-7F	KX-7	3.2 \| 2.5 \| 0.8 mm	12.0 MHz	8 pF	± 10 ppm
12.60021	16.0 MHz Quartz SMD KX-7	KX-7	3.2 \| 2.5 \| 0.8 mm	16.0 MHz	7 pF	± 10 ppm
12.60022	8.0 MHz Quartz SMD KX-7T	KX-7	3.2 \| 2.5 \| 0.8 mm	8.0 MHz	8 pF	± 20 ppm
